10 Ton compact single-acting stainless steel hydraulic cylinder with 2-inch (50mm) stroke and 103mm minimum height.

Country of origin: China

Brand: HARTLEY
Weight (Approx.) : 2.3 kg
Load Capacity : 10 ton
Lifting Range : 50 mm

Model No.: RSC-1050
Product Type: Single-Acting Hydraulic Cylinder Jack Ram
Load Capacity: 10 Ton (10T)
Stroke Length: 2 Inch (~50 mm)
Minimum / Closed Height: 103 mm
Material Type: Stainless Steel
Color: Yellow
Item Dimensions (L x W x H): 14 x 5 x 5 cm

The Hartley RSC-1050 is a compact, high-performance single-acting hydraulic cylinder jack designed for low-clearance lifting, pressing, pushing, and alignment tasks. Built with heavy-duty stainless steel and finished in a high-visibility yellow coating, this portable hydraulic ram delivers up to 10 tons of lifting force with a 50 mm (2 inch) stroke length. Operating on a single-acting hydraulic extension system with automatic spring return, it features a minimum retracted height of just 103 mm, allowing it to easily slide into confined industrial spaces. Designed with a flat base for maximum support, it operates with standard manual, foot, or electric hydraulic pumps.

Features

10-Ton Capacity: Delivers up to 10 tons of reliable hydraulic force for heavy-duty lifting and positioning.
Compact Low-Height Profile: Minimum closed height of 103 mm makes it ideal for low-clearance and tight working areas.
Single-Acting Spring Return: Hydraulic pressure extends the piston ram while an internal spring automatically retracts it when pressure is released.
Durable Stainless Steel Build: Premium stainless steel construction offers excellent resistance to wear, mechanical stress, and corrosion.
Universal Pump Compatibility: Pairs seamlessly with manual, foot-operated, or electric high-pressure hydraulic pumps.

Applications

Industrial Maintenance: Lifting, leveling, pressing, and precision alignment of heavy machinery in tight workshop spaces.
Vehicle & Fleet Service: Low-clearance jacking and frame straightening for ATVs, SUVs, and light utility vehicles.
Structural Engineering: Beam positioning, structural steel alignment, and bridge repair maintenance.

Usage

Positioning: Slide the compact cylinder directly under the workpiece on a flat, solid surface.
Hose Connection: Connect the high-pressure hose coupler from a compatible manual or electric hydraulic pump to the cylinder inlet.
Lifting/Pushing: Close the pump release valve and actuate the pump handle to extend the ram up to 50 mm.
Securing: Insert safety blocking or shims under the raised load before carrying out maintenance work.
Retracting: Slowly open the pump release valve to allow the internal spring to retract the ram completely.
