Brand: Imported

Heavy Duty 120 Amp Three Phase Air Plasma Cutter Welding Machine, with Standard Accessories

SKU: AB-MBI-20224280
Price : ₹79950 (Including GST)
Get extra ₹2,399 Discount (On Checkout)
Qty:
shopping_cart ADD TO CART
Easy Returns
Quality Assurance
Trusted Delivery
After Sales Assistance

Short Description

120 Amp Three Phase AIr Plasma Cutter
Air Cooled Machine
IGBT Module
22 kVA Rated Input Power
20-120A Current Adjust Range

Description

Heavy Duty 120 Amp Three Phase Air Plasma Cutter Welding Machine, with Standard Accessories

Features :
  • Inverter technology.
  • Low-cost cutting with high stability and stiff arc brings you smooth cutting and a small cutting angle.
  • Pilot Arc Start increases cutting efficiency.
  • Conveniently and quickly cut metal plate.
  • Built-in air filter and regulator.
  • Equipped with over/under voltage, as well as insufficient compressor air pressure protection.
  • Smooth cutting surface with high cutting speed.
  • They are widely used in cutting carbon steel, stainless steel, copper, cast iron, aluminum, etc.
  • Strengthened protection on the cutting torch connector largely enhances the operator's safety.
  • lnternationalStandard IEC 60974-1 & ISO 9001:2015 Certified

Specifications :
  • Model No. : LGK 120
  • Product Type : Air Plasma Cutter
  • Brand : Imported
  • BAse Material : Carbon steel, Stainless steel, Low - alloy steel
  • Input Power Supply : 415 V AC ± 10 %
  • Electricity Connection : Three Phase
  • Frequency : 50 Hz
  • Rated Input Current : 26 A
  • Rated Input Power : 22 kVA
  • No Load Voltage : 320 V
  • Current Adjust Range : 20-120 A
  • Duty Cycle : 60 %
  • Efficiency : 85 %
  • Power Factor : 0.93
  • lnsulation Class : H
  • Protection Grade : IP23
  • Machine Cooling Mode : Air Cooled
  • Cutting Thickness : 1-35 mm
  • Cutting pressure :  6-7 kg/cm
  • Switching Device : Module IGBT
  • Overall Dimension : (682 x 348 x 735) mm
  • Weight : 40 kg

Accessories :
  • Earthing Clamp
  • Welding Cable
  • Operator's Manual

Recommended areas of use :
  • Cutting steel and non-ferrous material
  • Gauging application
  • Bevel and hole cutting
  • Cutting of gratings
  • Stack cutting and shape cutting
  • Shipyard industries
  • Nuclear industries
  • Foundry industries
  • Pipe industries
  • Automotive and railroad components
