Brand : KBS
KBS 1.5Hp 15 Stage(4 inch) V4 Single Phase Water Cooled Submersible Pump, 300ft Head - 1 Year Warranty
5.0
SKU : TI-K1-21031
MRP : ₹10620
₹7339
31% OFF!
-
1
+
7 people have bought this recently
Get Extra  ₹110 OFF on Prepaid Orders
Delivery By: Oct 30 - Nov 1
Add to Cart
Buy Now
Easy Return
& Refund
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Buyer
Protection
Short Description
KBS 1.5 HP 1 Phase 15 Stage Submersible Pump
300ft Max. Head, 100 LPM Max. Flow Rate
4 inch Bore, V4 Type
1 Year Warranty
SPECIAL NOTE : THIS BOREWELL SUBMERSIBLE PUMP WORKS ON AC ELECTRIC POWER SUPPLY AND IS NOT COMPATIBLE WITH SOLAR PANEL SYSTEMS.
Country of origin: India
Specification
  • Brand: KBS
  • Power : 1.5 hp
  • Weight (Approx.) : 17 kg
  • Flow Rate : 100 lpm
  • Head : 91 meter
  • Product Type : Submersible Pump
  • Brand : KBS
  • Wattage : 1.1 kW
  • Supply Voltage : 180-220 Volt, 50 Hz, AC Power Supply
  • Electricity Connection : Single Phase
  • No Of Stages : 15 Stage
  • Pump Type : V4 Type
  • Suitable Bore Size : 4 inch (100 mm)
  • Cora : 2
  • Max. Head Range : 300 Feet (91 Meter)
  • Max. Flow/Discharge Rate : 100 LPM (6000 LPH)
  • Pipe Size (Suction x Delivery) : 25 x 25 mm (1 x 1 inch)
  • Cooling Type : Water Cooled

Material Of Construction :
  • Motor Body : Stainless Steel
  • Motor Rotor : Copper
  • Pump Bowl : Noryl (lvory)
  • Impeller : Noryl (lvory)
  • Motor Pipe : Stainless Steel
  • Bearing Bush : Leaded Bronze
  • Motor Shaft : SS-410
  • Thrust Bearing : Carbon Vs Stainless Steel
  • Stamping : CRNGO
  • Rotor : EC Grade Copper Conductor
  • Housing/Base/Connection Piece : CI (Grade FG-200/FG-220)
  • Suction/Outlet : CI (Grade FG-200/FG-220)
  • Diffuser : Noryl (Engineering Glass Filled)
  • Pump Shaft : SS-410
  • Pump Pipe : Stainless Steel
Description
This Borewell submersible pump is designed for extracting water from deep underground sources. These pumps are submerged in the water they are meant to pump, which allows them to operate efficiently at significant depths. A 1.5 hp borewell submersible pump is a compact yet powerful unit suitable for residential and agricultural applications where moderate water flow is required.

Features

 :
  • Corrosion resistant stainless steel body
  • Specially designed for low voltage working
  • High Electrical and Mechanical efficiency
  • Higher heat dissipation
  • Dynamically balanced rotor and other rotating parts for uniform clearance
  • Specially designed bearing to withstand axial thrust loads
  • Designed for high voltage fluctuation
  • High efficiency, low power consumption.

Applications

 :
  • Drinking water supply. Domestic & community water supply.
  • Drip irrigation, Sprinkler irrigation and gardening.
  • Housing-Complexes, Hospitals, High rise building.
  • Fire fighting, Landscaping, Fountains, Service stations.
  • De-watering of mines, Cooling water circulation and Booster application.

Warranty :
  • 1 Year WARRANTY on manufacturing defects only.

Warranty Terms :
  • Dry Run Accidental Damages Are not covered in the warranty
  • For claiming the warranty please drop a mail at [email protected] with proper bill or Order ID
  • You have to send the product to the sellers warehouse.
  • Buyer has to bear the courier charges of both side for sending the product.
