KBS 3Hp 15 Stage(4 inch) V4 Single Phase Water Cooled Submersible Pump, 120ft Head - 1 Year Warranty
SKU: TI-K3-21034
MRP : ₹23100
Offer Price : ₹14000 (Including GST)
Get extra ₹210 Discount (On Checkout)
Delivery By: Oct 13 - Oct 15
Qty:
BUY IN BULK
Easy Return & Refund
Quality Assurance
Trusted Delivery
After Sales Assistance
Buyer Protection
Short Description
KBS 3 HP 1 Phase 15 Stage Submersible Pump
120ft. Max. Head, 200 LPM Max. Flow Rate
4 inch Bore, V4 Type
1 Year Warranty
Country of origin: India
Description
This Borewell submersible pump is designed for extracting water from deep underground sources. These pumps are submerged in the water they are meant to pump, which allows them to operate efficiently at significant depths. A 3 hp borewell submersible pump is a compact yet powerful unit suitable for residential and agricultural applications where moderate water flow is required.
Features
:
Corrosion resistant stainless steel body
Specially designed for low voltage working
High Electrical and Mechanical efficiency
Higher heat dissipation
Dynamically balanced rotor and other rotating parts for uniform clearance
Specially designed bearing to withstand axial thrust loads
Designed for high voltage fluctuation
High efficiency, low power consumption.
Specification
:
Product Type : Submersible Pump
Brand : KBS
Power : 3.0 HP
Wattage : 2.2 kW
Supply Voltage : 200-220 Volt, 50 Hz, AC Power Supply
Electricity Connection : Single Phase
No Of Stages : 15 Stage
Pump Type : V4 Type
Suitable Bore Size : 4 inch (100 mm)
Cora : 4
Max. Head Range : 120 Feet (37 Meter)
Max. Flow/Discharge Rate : 200 LPM (12000 LPH)
Pipe Size (Suction x Delivery) : 50 x 50 mm (2 x 2 inch)
Cooling Type : Water Cooled
Weight : 40 Kg (Approx.)
Material Of Construction :
Motor Body : Stainless Steel
Motor Rotor : Copper
Pump Bowl : Noryl (lvory)
Impeller : Noryl (lvory)
Motor Pipe : Stainless Steel
Bearing Bush : Leaded Bronze
Motor Shaft : SS-410
Thrust Bearing : Carbon Vs Stainless Steel
Stamping : CRNGO
Rotor : EC Grade Copper Conductor
Housing/Base/Connection Piece : CI (Grade FG-200/FG-220)
Suction/Outlet : CI (Grade FG-200/FG-220)
Diffuser : Noryl (Engineering Glass Filled)
Pump Shaft : SS-410
Pump Pipe : Stainless Steel
Applications
:
Drinking water supply. Domestic & community water supply.
Drip irrigation, Sprinkler irrigation and gardening.
Housing-Complexes, Hospitals, High rise building.
Fire fighting, Landscaping, Fountains, Service stations.
De-watering of mines, Cooling water circulation and Booster application.
