2 Inch Threaded Bypass Tee with 3 Nos. Slip on Flange

Easy Returns

Quality Assurance

Trusted Delivery

After Sales Assistance

Short Description

Threaded Bypass Tee with 3 Nos. Slip on Flange

2 Inch Size

Description

2 Inch Threaded Bypass Tee with 3 Nos. Slip on Flange

Description :

• Slip on Flange is essentially a ring that is placed over the pipe end, with the flange face extending from the end of the pipe by enough distance to apply a weld bead on the inside diameter.
• Threaded Tees is a type of pipe fitting which is T-shaped having two outlets, at 90° to the connection to the main line.
• It is a short piece of pipe with a lateral outlet.


Features :

• Slip On : Good Resistance to strong acids except highly active oxidizers, such as nitric acid. It also has excellent resistance to weak and strong alkalies and to most organic solvents.
• It also has excellent resistance to weak and strong alkalies and to most organic solvents.
• Tees with Smooth Flow and minimal pressure drop.
• Sturdy and strong with a longer life
• UV Stabilized

Specifications :

• Model No. : HT-184
• Product Type : By Pass Tee with Slip On Flange
• Brand : Imported
• Size : 2 Inch or 50 mm
• Material : Reinforced Polypropylene

• Color : Black
• Tee Dimensions :
• (d) : 49.9 mm
• (L1) : 32.4 mm
• (L) : 183.8 mm
• (H) : 136.2 mm
• Max. Operating Pressure: 10 Bar/ 145 Psi

Applications :

• Pipe Tee is used to connect pipelines with a pipe at a right angle with the line.
• Pipe Tees are widely used in various commercial and industrial applications.
• Chemical processing
• Waste treatment
• Utilities/power generation

• Gas compression and distribution industries
