HPM 4 KVA 20.5L Portable Petrol Inverter Generator With Recoil Start(Oasis UL-40i-XL)

Brand : HPM

SKU : TI-H4-22487

MRP : ₹104930

₹69200

34% OFF!

Get Extra ₹1,038 OFF on Prepaid Orders

Delivery By: Jun 20 - Jun 22

Add to Cart

Buy Now

Easy Return
& Refund

Quality
Assurance

Trusted
Delivery

After Sales
Assistance

Buyer
Protection

Short Description

HPM 4 KVA Petrol Inverter Generator

Recoil Start

16.5 Amp Rated Current Of Generator

20.5 Ltr. Fuel Tank Capacity

14 hrs. Run Time

Country of origin: India

Specification

Brand: HPM
Weight (Approx.) : 36.5 kg
Fuel Used : Petrol

Model No. : Oasis UL-40i-XL

Generator :

Max AC. Output VA : 4000
Rated AC. Output VA : 3800
Rated Current Amps : 16.5
NFB Amps : 17
AC. Voltage : 230 Volts ± 1%, 50 Hz ± 1%, Single Phase, THD < 2%
Alternator Type : Multi-Phase – Permanent Magnet (18 Pole) – Self Excitation
Invertor : 100 KHz, IGBT Based Digital Invertor – 4 Kw

DC Outputs :

DC Outputs - 5V to 20 V & DC Ports
USB Output (1 to 2) : 2* 5V DC, 2.4 A (12W Per Port)
USB Output Fast Charging QC 3.0 (3) : 1* 5V - 12V DC (18W-Max) 5V3A, 9V 2A, 12V 1.5A
Type - C USB (4) : 1* 'C' Type - 1* USB C PD 2.0 (30W) 5V 3A, 9V 3A, 12V 1.5A 15 V 1.5A 20 V 1.5A

Engine :

Model : HM170P
Type : OHV25°Inclined, Single Cylinder,4 Strokes, S.I, Forced Air Cooling
Maximum Power : 6.5 HP @ 3600
Bore x Stroke :70x58 mm
Displacement : 223 cc
Starting System : Recoil Start
Governor : Electronic Governor (Load Sensitive – Variable Speed) Engine RPM 2200 (No Load) to 3800 RPM (at Full load)
Fuel : Petrol
Fuel Tank Capacity : Petrol -20.5 Ltr.
Fuel Consumption : Petrol 1.5 ltr/hr Approx.
Lube. Oil Capacity : 600 ml.
Lubricating Oil Consumption : 2.5 gm./Hr.
Sound level (Db) (from 1 meter) : < 86Db (as per CBCP - II Norms)
Continues Running (With One Filling) : 14 Hrs. Approx.

Panel & Other Standard Features :

Multifunction Digital Meter & Indicator : Digital Control Panel (V, Hz, Amp)
Oil Alert System : Yes
Over Load Indicator : Yes
2 Genset Paralleling Capability : Yes, Red & Black Pair of Sockets Provided in Control Panel for Paralleling of 2 Generators
Fuel Level Gauge : Yes
AC On /Off, Overload Protection (NFB) : Yes
Electronic Over Load Protection : Yes, Inbuilt with Inverter

Description

The HPM Oasis UL-40i-XL is a 4 KVA portable petrol inverter generator with recoil start. It delivers clean power, low noise , and high fuel efficiency. Ideal for camping, RVs, and small households, it features automatic voltage regulation, overload protection, and a durable design. Weighs 36.5kg, with extended 20.5L fuel tank for 14 hours runtime.

Features

4 KVA Genset, Ultra-Light Weight, Digital Invertor Based Alternator, Electronic Governor keeps Low Engine RPM at part loads for low fuel consumption.
Gives a Stable Regulated voltage 230 ± 1 % and Stable Frequency 50 Hz ± 1 % & Pure Sine Wave, THD < 2 %
To get more Power to Run Heavy Equipment, 2 or More HP 40i Generator can be made to Run In Parallel, Two HP40i Generators in Parallel will produce 4 KVA + 4 KVA = 8 KVA Power

Applications

Being Light Weight and Portable Genset, It is very suitable for serving electrical requirements in remote areas / Field applications and running of sensitive Electronic Products Like Laptops / Computers / Digital Appliances, For charging Inverters, for all types of Frequency & Voltage sensitive Equipment’s, Military & Powering Defense Equipment’s Etc.

Accessories

Owner Manual 1 pc
Funnel 1 pc
Screw Driver 1 pc
Spanner 1 pc
Three Pin Plug 1 pc
