• Diameter (inlet/outlet size): 2 inch (50 mm)
• Flow rate: 30 cubic meters per hour
• Filter mesh size: 120 microns (120 mesh)
• Weight: Approximately 5.6 kg
• Material: Corrosion-proof polypropylene body with stainless steel filter discs
• Maximum working pressure: 6 kg/cm²
• Filtration surface area: 878 cm²
• Cartridge diameter: Around 122 mm
• Cartridge length: Approximately 305 mm
• Installation: Suitable for vertical and horizontal positions; inline and angular connections possible
• Country of origin: India

Features

• 2 inch (50 mm) inlet/outlet size suitable for standard irrigation pipes
• Maximum working pressure of 6 kg/cm²
• 120 mesh (micron) filter aperture for effective particle retention
• Nominal flow rate of approximately 25-30 cubic meters per hour
• Durable body made from corrosion-proof polypropylene
• Stacked disc structure providing three-dimensional filtration
• Retains coarse particles on the surface and fine particles in grooves
• Installation possible in any position: vertical or horizontal
• Inline and angular inlet-outlet connection options
• Easy flushing of trapped impurities via drain valve
• Resistant to common agricultural chemicals and fertilizers
• Low maintenance with longer intervals between cleaning
• Lightweight, approx. 4.5 to 5.6 kg, for easy handling

Applications

• Used in drip irrigation systems for filtering water to prevent emitter clogging
• Suitable for agricultural water filtration to protect pipes and sprinkler components
• Applied in industrial water filtration processes requiring 120-micron particle removal
• Used in garden lawns and landscaping irrigation to maintain clean water flow
• Suitable for filtration in swimming pool water circulation systems
• Ideal for capturing organic and inorganic dirt, debris, and suspended particles in irrigation water
• Can be installed inline or at angle positions for flexible system layouts
• Supports chemical-resistant operation with agricultural fertilizers and flushing agents

Usage

• Install the filter inline or at an angle in your irrigation pipeline (vertical or horizontal position).
• Connect the 2 inch inlet and outlet to the irrigation system pipes securely using compatible fittings.
• Use the drain valve to flush out trapped dirt and debris regularly to maintain filter efficiency.
• Position the filter to allow easy access for cleaning and maintenance.
• Use with agricultural water containing fertilizers and chemicals as the body is resistant to such agents.
• Ensure proper sealing to avoid leaks and maintain steady water flow through the filter.
• Periodically inspect the stacked disc elements for wear and replace if needed for optimum filtration.
• These usage tips help maintain performance and extend the life of your irrigation system by preventing clogging.​
