Brand: Automat
Automat 3 Inch Semi Automatic Disc Filter for Primary & Secondary Filtration
SKU: JS-HA-2021244
10 people have bought this recently
Delivery By: Jul 17 - Jul 19
MRP : ₹10000 ₹7900
21% OFF!
10 people have bought this recently Delivery By: Jul 17 - Jul 19 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹7900 (Including GST)
MRP : ₹10000
21% OFF!
Get Extra ₹119 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
3 Inch (7.62 cm approx) Semi Automatic Disc Filter for Primary & Secondary filtration
Country of origin: India
Specifications
- Brand: Automat
- Weight (Approx.) : 11.5 kg
- Model No : AQ-136T-SAD
- Inlet/outlet connection : 3" (80 cm) BSP/NPT male thread
- Maximum Flow Rate : 40 m3/HR
- Maximum working Pressure : 85 PSI
- Filtration Surface Area : 251 inch2
- Filtration Degree : 200 Mesh
- Material : Stainless steel
Warning : In order to prevent water hammer (surge) always open or close filter handle valves in a gradual motion.
Description
The Semi-Automatic Disc Filter offers reliable filtration with minimal maintenance. Made from a durable, chemically bonded polymer, it ensures long-lasting performance. The user-friendly design allows for easy installation and efficient cleaning with a simple 90-degree handle rotation, keeping the irrigation system clog-free.
Features
:- Durable Construction: Built with a chemically bonded polymer for long lasting use.
- Hydro Cyclonic Effect: Disc housing fan keeps particles in suspension, reducing cleaning frequency.
- Clogging Indicator: Red pop-up button alerts when cleaning is needed.
- Efficient Cleaning: 90-degree handle rotation enables cleaning without dismantling the filter
Applications
:- Pre-filtration in desalination plants
- Surface water filtration for irrigation
- Filtration in hydroponics systems
- Clarification of wastewater
- Tertiary treatment for high-quality effluent
Cleaning Instructions :
- Cleaning of the filter must be done when pressure differential across the disc reaches 0.6 kg/cm2 (8.5psi) or when the clogging indicator red button pops up.
- Cleaning the semi-automatic filter must be done while the filter is under pressure
- Gradually open the flushing valve below the filter
- To start cleaning mode of filter, turn the handle (top of the filter) 900 degree in clockwise direction.
- Cleaning operation starts, system pressure might increase during cleaning operation.
- When cleaning operation done, first filter handle direction should be at filtration mode. And then flushing valve gradually close.
- In case the the filter is still clogged (pressure indicator button is up). Repeat the above steps for effective disc cleaning.
