Brand: Toshweld
Toshweld 250 Amp Single Phase MOSFET Welding Machine With 1 Year Warranty (ARC 250 ST)
SKU: TI-T2-51457
Delivery By: Dec 9 - Dec 11
MRP : ₹15273 ₹11749
23% OFF!
Delivery By: Dec 9 - Dec 11 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹11749 (Including GST)
MRP : ₹15273
23% OFF!
Get Extra ₹176 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
Input Voltage AC 230V ± 15% (Single Phase)
Output Current Range 10 - 250 Amps
Technology MOSFET Inverter
1 Year Warranty
Country of origin: China
Specifications
- Brand: Toshweld
- Weight (Approx.) : 10 kg
- Output Current Range : 250 amp
- Technology : MOSFET
- Model : ARC 250 ST
- Technology : MOSFET Inverter
- Input Voltage : AC 230V ± 15% (Single Phase)
- Plate Thickness Capacity : 2.0 mm - 8.0 mm
- Compatible Electrode Size : 2.0 mm - 4.0 mm
- No-Load Voltage : 58 V
- Input Power Capacity : 7.4 KVA
- Rated Input Current : 43.6 A
- Power Factor : 0.73
- Net Weight : 10 KG
- Dimensions : 16" x 6" x 12"
- Warranty : 1 Year
Description
Boost your fabrication efficiency with the Toshweld ARC 250 ST. This compact Single Phase MOSFET welder delivers a reliable 250 Amp output, perfect for light to medium-duty projects. Weighing just 10kg, it easily welds plates up to 8mm thick. Ideal for home workshops, mobile repairs, and DIY enthusiasts. Includes a 1-year warranty.
Features
:- Proven MOSFET Technology Delivers consistent arc stability and is well known for durability and low cost maintenance over time
- High Performance Output Generates a variable current from 10 to 250 Amps allowing for precise control on various metal thicknesses
- Compact and Portable Design Weighing only 10kg with a slim profile this machine is easy to carry for on site repair jobs
- Versatile Material Welding Capable of welding steel plates from 2.0mm up to 8.0mm thick ensuring strong joints for light fabrication
- Standard Voltage Compatibility Operates on standard single phase 230V power making it perfect for home plugs and small workshops
Accessories
:- 1.5 Meter Welding Cable With Holder
- 1.5 Meter Welding Cable With Earthing Clamp
Applications
:- Home DIY Projects and Hobbyists
- Light Fabrication of Gates and Grills
- Mobile Repair and Maintenance Services
- Automotive Bodywork and Repairs
- Small Workshop Metal Joining
Usage
:Usage Guidance (How to use) :
- Power Connection Plug into a standard 230V outlet ensuring the circuit breaker handles the 43.6A rated input for maximum power
- Rod Selection Use electrode rods between 2.0mm and 4.0mm depending on the thickness of the steel you are working on
- Amperage Control Start with lower amps for thin sheets and increase current for thicker plates up to the 250A maximum
- Safety Precautions Always wear safety glasses, a welding helmet, and flame resistant gloves to protect yourself from sparks
Maintenance Guidance :
- Ventilation Cleaning Blow compressed air through the side vents monthly to remove dust accumulation from the MOSFETs
- Cable Inspection Regularly check the power cord and welding leads for any cuts or loose connections to ensure safety
- Moisture Avoidance Store the machine in a dry cabinet or shelf away from damp floors to protect the internal electronics
