• Power : 7500VA

• AC Voltage : 220/230/240VAC
• Voltage Range : 170-280VAC（For Personal Computers；） 90-280 VAC（For Home Appliances）
• Frequency Range : 50/60H（z Auto sensing）

• Surge Power : 12000VA
• Voltage Regulation (Battery Mode) : 220VAC/230VAC/240VAC ± 5%
• Rated Frequency : 50/60Hz
• Efficiency (Peak) : 93%
• Transfer Time : 10ms（For Personal Computers), 20m（s For Home Appliances)

• Battery Voltage : 48VDC
• Floating Charge Voltage : 54VDC
• Overcharge Protection : 63VDC
• Battery Type : Lithium/Lead-acid

• Maximum PV Array Open Circuit Voltage : 500VDC
• Maximum PV Array Power : 5000W
• MPPT Voltage Range(V) : 90~450VDC
• Maximum Input Current : 27A
• MPPT Tracker/Strings : 1
• Maximum Solar Charge Current : 120A
• Maximum AC Charge Current : 100A
• Maximum Charge Current : 120A

• AC Overcurrent : Yes
• AC Overvoltage : Yes
• Over Temperature Protection : Yes
• Smart Load Management : Yes
• On Grid : Yes
• Parallel Function : Yes, 6 Units
•

• GENERAL PARAMETERS
• Operation Temperature : -10°C ~ 50°C
• Relative Humidity : 5% ~ 95% (Non-condensing)
• Altitude : (>2000m Derating)
• Dimensions (D x W x H) : 31.5 x 13.4 x 51.6 cm

• Display : Touch screen
• Interface : Standard : RS232, CAN & RS485, Optional : Wi-Fi, Bluetooth, CT
• Safety Standard : EN/IEC 62109-1,EN/IEC 62109-2

Features

• 7.5KVA Capacity – Provides robust power backup for various applications.
• Hybrid Functionality – Supports both on-grid and off-grid operations.
• MPPT Technology – Maximizes solar energy utilization for improved performance.
• Pure Sine Wave Output – Ensures stable and smooth power for sensitive appliances.
• Advanced Protection – Includes overload, short circuit, and overcharge safeguards.
• Energy-Efficient Operation – Reduces electricity consumption and enhances battery life.
• Smart LCD Display – Allows easy monitoring of system performance.
• Compact & Durable Design – Ensures long-term reliability and easy installation.
