UTL Hybrid Solar 10kVA HYB-10-GXLT2 Solar Hybrid Inverter Designed for Residential Use
SKU: TB-UJ-33581
7563 people have viewed this recently
Estimated Delivery By: Nov 24 - Nov 26




MRP : ₹250000 ₹220000
12% OFF!

7563 people have viewed this recently
Estimated Delivery By: Nov 24 - Nov 26
Easy Return
& Refund
& Refund

Quality
Assurance
Assurance

Trusted
Delivery
Delivery

After Sales
Assistance
Assistance

Buyer
Protection
Protection
₹220000 (Including GST)
MRP : ₹250000
12% OFF!
Get Extra ₹3,300 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
Residential use
Solar Inverter
Country of origin: India
Specifications
- Brand: UTL
- Weight (Approx.) : 35 kg
- Ideal For : Men and Women
Battery Input Data
- Battery Type : Lithium Ion Battery
- Battery Voltage Range(V) : 40-60
- Max. Charging Current(A) : 210
- Max. Discharging Current(A) : 210
- Charging Strategy for Li-ion Battery : Self Adaption to BMS
- Number of Battery Input : 1
- Max. PV Input Power(W) : 15000
- Max. PV Input Voltage (V) : 800
- Start-up Voltage(V) : 160
- PV Input Voltage Range(V) : 160-800
- MPPT Voltage Range(V) : 200-650
- Full Load MPPT Voltage Range (V) : 250-650
- Rated PV Input Voltage(V) : 550
- Max. Operating PV Input Current(A) : 20+20
- Max. Input Short-Circuit Current(A) : 30+30
- No. of MPP Trackers/No. of Strings MPP Tracker : 2/1 + 1
- Max. Inverter Back-feed Current to The Array : 0
AC Input / Output Data
- Rated AC Input / Output Active Power(W) : 10000
- Max. AC Input / Output Apparent Power(VA) : 11000
- Peak Power (off-grid)(W) : 2 times of rated power, 10s
- Rated AC Input / Output Current(A) : 15.2/14.5
- Max. AC Input / Output Current(A) : 16.7/16
- Max. Continuous AC Passthrough (grid to load) (A) : 45
- Rated Input / Output Voltage/Range(V) : 220/380V, 230/400V 0.85Un-1.1Un
- Grid Connection Form : 3L+N+PE
- Rated Input / Output Grid Frequency/Range : 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz
- Power Factor Adjustment Range : 0.8 leading-0.8 lagging
- Total Current Harmonic Distortion THDI : <3% (of nominal power)
- DC Injection Current : <0.5%In
- Max. Efficiency : 97.60%
- Euro Efficiency : 97.00%
- MPPT Efficiency : >99%
- DC Polarity Reverse Connection Protection : Yes
- AC Output Overcurrent Protection : Yes
- AC Output Overvoltage Protection : Yes
- AC Output Short Circuit Protection : Yes
- Thermal Protection : Yes
- DC Terminal Insulation Impedance Monitoring : Yes
- DC Component Monitoring : Yes
- Ground Fault Current Monitoring : Yes
- Arc fault circuit interrupter (AFCI) : Optional
- Power Network Monitoring : Yes
- Island Protection Monitoring : Yes
- Earth Fault Detection : Yes
- DC Input Switch : Yes
- Overvoltage Load Drop Protection : Yes
- Residual Current (RCD) Detection : Yes
- Surge Protection Level : TYPE II(DC), TYPE II(AC)
- Display : LCD+LED
- Communication Interface : RS232, RS485, CAN
- Monitor Mode : GPRS/WIFI/Bluetooth/4G/LAN(optional)
- Operating Temperature Range : -40 to +60 C, >45 C Derating
- Permissible Ambient Humidity : 0-100%
- Noise : ≤ 55 dB
- Ingress Protection(IP) Rating : IP 65
- Inverter Topology : Non-Isolated
- Over Voltage Category : OVC II(DC), OVC III(AC)
- Cabinet size(W*H*D) [mm] : 386W×660H×250D (Excluding connectors and brackets)
- Weight(kg) : 35.2
- Warranty : Standard 5 years, extended warranty
- Type of Cooling : Intelligent Air Cooling
- Grid Regulation : IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097,RD 140, UNE 217002,OVE-Richtlinie R25, G99, VDE-AR-N 4105
- Safety EMC/Standard : IEC/EN 61000-6-1/2/3/4, IS 16221/IEC 62109, IS 16169/IEC 62116
Description
The UTL Hybrid Solar 10kVA HYB-10-GXLT2 is a high-frequency, three-phase, transformer-less hybrid solar inverter perfectly engineered to meet the heavy power demands of modern residential homes and small businesses. Equipped with advanced Dual MPPT technology (yielding over 99% tracking efficiency), it expertly manages power between your solar panels, battery storage, and the grid to minimize electricity bills. Its sleek, wall-mountable design seamlessly integrates with both new and retrofit installations. Offering compatibility with both Lithium-ion and Lead-acid high-voltage batteries, smart load functions, and an AC-coupled setup, this intelligent inverter provides reliable, uninterrupted green power while maximizing your solar utilization.
Features
:- Dual MPPT Technology: Features two independent Maximum Power Point Trackers with >99% efficiency for optimal energy harvesting from solar panels.
- Smart Load & Multi-Mode Operation: Highly programmable operation modes (on-grid, off-grid, and UPS) and user-settable priority modes (Solar First, Battery First, or Grid First).
- Three-Phase Power Output: Safely manages and outputs a balanced 10kW three-phase power supply to run heavy residential or commercial loads smoothly.
- Universal Battery Support: fully compatible with high-voltage Lithium-ion (Li-ion) and traditional Lead-acid batteries, with a powerful 50A maximum charging/discharging current.
- Expandable & Scalable: Supports parallel operation, allowing you to connect up to 10 inverter units simultaneously for system upgrades and larger capacity needs.
- Transformer-less & Compact: A sleek wall-mounted, high-efficiency (97.6%) transformer-less design that is easy to install and runs quietly.
- Built-in Export Limitation: Allows users to intelligently restrict surplus power from feeding back into the grid where net metering is not allowed.
- Advanced Remote Monitoring: Equipped with an LCD + LED interface and supports GPRS, Wi-Fi, Bluetooth, LAN, and 4G for real-time tracking of energy generation and consumption via a mobile app.
- Robust Protection: Incorporates advanced safeguards including short-circuit protection, overload control, and over-temperature safety limits.
