Brand: WeldTron
Weldtron 250A 1+2 Phase 5-PCB IGBT Inverter Welder 45N120 ARC-250K
SKU: TI-W2-67605
Estimated Delivery By: Apr 8 - Apr 10
MRP : ₹13519 ₹10399
23% OFF!
Estimated Delivery By: Apr 8 - Apr 10 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹10399 (Including GST)
MRP : ₹13519
23% OFF!
Get Extra ₹156 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
Weldtron ARC250K 250A dual-phase inverter MMA welder with 5-PCB design, 4x 45N120 IGBTs, 9238 fan cooling, and VRD switch for heavy industrial fabrication and maintenance.
Country of origin: India
Specifications
- Brand: WeldTron
- Weight (Approx.) : 7 kg
- Output Current Range : 250 amp
- Technology : IGBT
- Model: ARC250K
- Input Voltage: 220V 1-Phase / 380V 2-Phase (1+2 Phase)
- Output Current: 30-250A (Adjustable)
- IGBT Modules: 4 x 45N120 (1200V/45A)
- Rectifier Diodes: 4 x 6030 (High Current Fast Recovery)
- Capacitors: 4 x 400V 680uF (Heavy Duty Filter)
- Cooling Fan: 1 x 9238 (High CFM Industrial Grade)
- Controls: Two Knobs + VRD Switch
- Duty Cycle: 60% @ 250A / 100% @ 185
- Open Circuit Voltage: 70-80V DC (VRD: <18V)
- Efficiency: ≥88%
- Power Factor: 0.93
- Insulation Class: H (180°C)
- Protection: IP23S / Overheat / Overcurrent
- Electrode Size: 2.5-6.0mm
- Dimensions: 320mm*164mm*295mm
Description
The Weldtron ARC250K uses a sturdy 5-PCB architecture and advanced 1+2 phase operation (compatible with 220V and 380V) to generate 250A of output. It offers steady arc performance for 2.5-6.0mm electrodes using four 45N120 IGBT modules, four 6030 diodes, and four 400V 680uF capacitors. Dual knobs provide accurate current/voltage regulation, and the potent 9238 high-CFM fan guarantees constant cooling. By reducing open-circuit voltage, VRDs (Voltage Reduction Devices) improve safety. With dimensions of 320x164x295mm and a weight of under 5.1 kg, it is perfect for professional welders who want dual-voltage capability.
Features
:- Both 220V single and 380V two-phase power sources are supported by the 1+2 phase input.
- 5-PCB modular architecture makes component replacement easier and increases reliability.
- Smooth high-frequency arc control is provided by four 45N120 IGBTs (1200V/45A).
- Efficient rectification with low heat is ensured by four 6030 high-current diodes.
- Stable filtering for ripple-free output is provided by four 400V 680uF capacitors.
- During prolonged operation, the high-performance 9238 axial fan keeps the temperature at its ideal level.
- Two control knobs allow for accurate voltage and amperage adjustment.
- For safer handling, the VRD safety switch lowers the open-circuit voltage.
- Arc ignition and electrode release are improved by hot-start and anti-stick features.
Applications
:- Structural framework welding and heavy steel fabrication.
- Equipment repair and maintenance for industrial plants.
- Substantial maritime fabrication and shipbuilding.
- Large-scale infrastructure building initiatives.
Usage
:- For maintenance, switch to 220V single phase; for production, switch to 380V two phase.
- Current knob: 190-250A (5.0-6.0mm electrodes), 110-170A (3.2-4.0mm).
- For safe handling, turn on the VRD switch; to weld, detach it.
- Keep the arc length between 3 and 5 mm; fine-tune the arc characteristics using the voltage knob.
