• Power: 240V/500W
• Speed: 0-60 pc/min
• Bottle Diameter: 20-120mm
•  Dimension(mm) : 340 *290 *130

Features

• Expanded Sealing Range (20-120 mm): This key feature allows the machine to seal a significantly broader spectrum of cap diameters, from small 20mm caps to large 120mm caps, providing unparalleled versatility for different container sizes across various product lines.

• Non-Contact Induction Sealing: Employs advanced electromagnetic induction to generate heat directly within the foil liner, creating a strong, hermetic, and tamper-evident seal without physical contact with the product, ensuring hygiene and preventing contamination.

• Precise Power and Time Control: Equipped with adjustable power (wattage) and sealing time settings, enabling operators to fine-tune the induction strength and duration precisely to match different cap materials, foil liners, and container types for consistently optimal sealing quality.

• Automatic Overheat Protection: Incorporates built-in safety mechanisms that detect and prevent overheating, automatically shutting down the unit if temperatures exceed safe limits, thereby protecting the machine and prolonging its lifespan.

• User-Friendly Interface & Portability: Features an intuitive control panel for easy operation and parameter adjustment. Its relatively compact and often portable design allows for flexible integration into various production environments, from small-scale operations to larger lines requiring mobility.

Applications

• Pharmaceuticals & Nutraceuticals: Sealing large and small medicine bottles, vitamin containers, protein powder jars, and liquid medication bottles to ensure sterility, prevent tampering, and maintain product efficacy.

• Food & Beverages: Sealing wide-mouth jars for jams, pickles, condiments, and dry goods, as well as various sizes of juice, dairy, and sauce bottles, preserving freshness and preventing leakage for a longer shelf life.

• Cosmetics & Personal Care: Sealing large tubs of creams, lotions, hair products, and smaller cosmetic jars, preventing spills, ensuring product integrity, and extending freshness.

• Chemicals & Industrial Products: Sealing containers for a wide range of industrial liquids, cleaning agents, automotive fluids, glues, and agricultural chemicals, ensuring safe transport, storage, and preventing contamination.

• Household & Retail: Ideal for sealing various household products like detergents, pet food containers, and other retail items that benefit from a secure, tamper-evident closure.

Usage

• Preparation: Ensure the container is filled with product and securely capped with an induction-compatible cap that contains a foil liner. Plug the sealer into a power source and allow any necessary warm-up.

• Setting Adjustment: Based on the container's cap size (20-120mm), material (e.g., HDPE, PET, Glass), and foil liner type, precisely set the induction power and sealing time using the control panel.

• Sealing Process: For manual models, position the sealing head directly over the capped container, ensuring it is centered. For semi-automatic conveyor models, place the container on the conveyor belt to pass under the induction head. Activate the sealing cycle.

• Verification: After the sealing process, remove the container and visually inspect the foil seal. It should be uniformly bonded to the container's mouth, appearing smooth, wrinkle-free, and securely attached, indicating a perfect seal.

• Operation & Shutdown: Continue the sealing process for subsequent containers, periodically checking seal quality. When finished, turn off the machine and unplug it from the power source for safety.

• Regular Cleaning: Unplug the unit and allow it to cool completely. Gently wipe the exterior, especially the sealing head and control panel, with a soft, dry or slightly damp cloth to remove any dust, spills, or foil particles. Avoid using abrasive cleaners or spraying water directly on the machine.

• Cable and Connection Integrity: Periodically inspect all power cords and connection cables (especially to the sealing head) for any signs of wear, cuts, or physical damage. Ensure all connections are tight and free from corrosion to maintain electrical safety and performance.

• Ventilation Management: Keep the machine's cooling vents and fan grilles clear of any dust, lint, or obstructions. Adequate airflow is crucial for dissipating heat generated during operation and preventing the internal components from overheating, thus extending the unit's lifespan.

• Optimal Liner Use: Always ensure that only high-quality induction foil liners, specifically designed to be compatible with both your container material (e.g., PP, PET, HDPE, glass) and the induction sealer's power specifications, are used for consistent and reliable sealing results.

• Scheduled Professional Servicing: Adhere to the manufacturer's recommendations for periodic professional maintenance checks. This includes internal component inspection, calibration verification, and addressing any potential issues proactively to prevent breakdowns and ensure continuous peak performance.
