Brand:
HPM
Heavy Duty Diesel Concrete Vibrator, 208CC
SKU:
SAC-CV-1088
Regular Price :
₹40000
Offer Price :
₹32540
(Including GST)
Qty:
remove
1
add
article
GET BULK QUOTE
flash_on
BUY NOW
Delivery By: Jun 1 - Jun 6
chat
Chat with us
shopping_cart
ADD TO CART
shopping_cart
ADD TO CART
flash_on
BUY NOW
Easy Returns
Quality Assurance
Trusted Delivery
After Sales Assistance
Short Description
Displacement 208cc
Max. Power Output 4 HP
RPM 3600
Fuel Capacity 3.0 Liter
Description
Heavy Duty Diesel Vibrator, 208CC
Specifications :
Product Type : Concrete Vibrator
Brand : HPM
Discharge Diameter : Ø45
Max. Capacity (L/min) : 1200
Hose Length : 6 Mtrs
No-load vibration frequency : >183Hz
Max.amplitude : 1.2m
Productivity : 15 m3/h
Engine Specifications :
Engine Type : 4-Stroke, OHV, Single Cylinder, Direct Injection, Swirl Chamber, Inclined type
Bore*Stroke : 70*54 mm
Displacement : 208cc
Compression Ratio : 22:01
Cooling Type : Force Air-Cooled
Max. Power Output : 4 HP (2.8)KW
RPM : 3600
Starting System : Recoil
Engine Oil Capacity : 700 ml.
Lubrication Type : Splashing
Lubricating Oil Consumption : ≤ 4.08 gm./Kw.hr.
Lubrication Oil Grade : Servo SAE Grade 10W30 or Equalant, or Servo 15W40
Fuel Capacity : 3.0 Liter
Fuel Type : Standard Diesel
Min. Fuel Consumption : ≤290 g/kw/h
Air Cleaner : Semi-dry; oil bath; dual
Packing Dimension (Box Size)-mm : 470*395*420 mm
Weight (without lead) 28.5 kg
