Brand : Generic (Imported)
Double Nozzle Paste Filling Machine 100-1000 ml, Semi-Automatic
4.0
SKU : DAR-SH-2130
MRP : ₹79999
₹68999
14% OFF!
-
1
+
4 people have bought this recently
Get Extra  ₹1,035 OFF on Prepaid Orders
Delivery By: Oct 31 - Nov 2
Add to Cart
Buy Now
Easy Return
& Refund
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Buyer
Protection
Short Description

Double Nozzle Paste Filling Machine , Semi-Automatic

Filling Volume : 100-1000 ml

It is suitable for filling viscosity liquid-like sauce, jam, shampoo, lotion, perfume, etc with soft particulate.

Country of origin: China
Specification
  • Brand: Generic (Imported)
  • Weight (Approx.) : 45 kg
  • Body Material : Stainless Steel
  • Power source : 220V/110V
  • Phase : Single
  • Frequency : 50Hz
  • Filling Head : Double Head
  • Filling Volume : 100-1000 ml
  • Capacity of Hopper : 20 L
  • Air Supply : 400 LPM
  • Air Pressure : 0.8 Mpa
  • Efficiency : 1500 bottles per hr

NOTE : This machine is not suitable for Grease filling.
Description
This Item is ideal semi-auto filling equipment for medicament, light industry, food, pesticide and other special industry. Simple operation is the main feature of the machine. The piston and hopper of the cylinder are made up of 304 stainless steel and Polytetrafluoroethylene (PTEF). It accords with GMP requirement. The filling range and speed are adjustable. Filling unit has a function of leaking-proof, silk nuzzling-proof. The machine is able to change to multi-head, burst-proof and flood-proof filling unit according to the requirement of customers.

Features

 :
  • Semi-automatic piston type filling machine.
  • Automatic and manual switch, Emergency stop switch, you could stop and start the machine at any time.
  • High accuracy filling, Filling volume and speed can be arbitrary regulation.
  • Simple and reasonable structure, easy operation. All the parts that will contact the materials were made of 304 stainless steel, large-scope chrome plating structural parts, effectively prevent rust and stuck.
  • This pneumatic filling machine is of wide applicability.
  • It is suitable for filling viscosity liquid-like sauce, jam, shampoo, lotion, perfume, etc with soft particulate.

Applications

 :
  • Food Industry : It is suitable for filling sauces, jams, and other thick food products.
  • Cosmetics : The machine can fill creams, lotions, and gels used in personal care products.
  • Pharmaceuticals : It is utilized for dispensing ointments and other viscous medicinal products.
  • Chemical Industry : The machine can handle adhesives and other thick chemical substances.

Usage

 :
Setup the Machine :
  • Place the machine on a stable, flat surface.
  • Ensure that all parts are securely assembled according to the manufacturer’s instructions.
Adjust the Filling Volume :
  • Set the desired filling volume (between 100-1000 ml) using the adjustment knob.
Prepare the Paste :
  • Ensure that the paste is at an appropriate viscosity for filling. If necessary, mix or dilute it to achieve optimal flow.
Fill the Hopper :
  • Pour the prepared paste into the hopper of the machine, ensuring not to overfill.
Select Operating Mode :
  • Choose between manual or automatic mode based on your production needs.
Start Filling Process :
  • Press the start button or activate the foot pedal to begin filling.
  • Monitor the process to ensure consistent filling and check for any clogs or issues.
Collect Filled Containers :
  • Position containers under the nozzle to catch filled paste.
  • Ensure containers are stable and aligned properly for accurate filling.

Maintenance :
  • Regular Cleaning : After each production run, thoroughly clean all parts that come into contact with the paste. This includes the filling nozzle, hopper, and any other components.
  • Inspection for Wear and Tear : Conduct regular visual inspections to check for signs of wear, leaks, or corrosion on seals and gaskets.
