Automat 2 Inch Eco Disc Filter for Filtration

Features

• Flow passes through outside to Inside of Disc cartridge.
• Uniform distribution of flow into filter housing optimize filtration process.
• Filter designed for Max. Operating Pressure 6 BAR (PN 6).
• ¼" (0.635 cm approx) Male threaded 2 pressure ports .
• Spring Loaded disc cartridges for uniform compression of disc.
• Fast cleaning of disc cartridge because of self loosen design.
• Union Nut for easy dismantling of filter for fast cleaning operation.
• Filter body cap equipped with ½" (1.27 cm approx) female threaded connection for draining.
• Grooved disc design with dimensional consistency proven with more than 95% filter efficiency

Applications

• Model No : HT-133TM
• Size : 2 Inch (5.08 cm approx)
• Max. Working Pressure : 6kg/cm2
• Inlet/ Outlet Connection : 2 Inch BSP/NPT Male Thread
• Range of Flow Rate : 10 -20 m3/hr
• Recommended Flow : 15 m3/h (250 ltr/min)
• Filtration Surface Area : 409 cm2
• Filter Height : 345 mm
• Filter Width : 140 mm
• Cartridge Diameter : 70 mm
• Cartridge Length : 208 mm
• End Plug : 1/2 inch (1.27 cm approx) Threaded
