• Product Type : Welding Machine
• Brand : Generic
• Power Voltage :  3Ph AC380V±15%

• Frequency : 50Hz
• Rated Input Current : 19.5A
• Rated Input Power : 13.5KVA
• No Load Voltage : 68 V

• Current Adj. Range TIG Mode (A) : 5-400

• Current Adj. Range ARC Mode (A) : 10-400

• Duty Cycle : 60%

• Remote Function : Yes

• Ignite Method : HF
• Efficiency : 85%
• Power Factor : 0.93
• Insulation Class : H

• Protection Grade : lP23

• Pre-flow (S) : 0-5

• Pulse width (%) : 10-90

• Down Slope (S) : 0-10

• Post flow (S) : 0.1-20

• Pulse frequency (Hz) : 0.5-500

• Overall Dimension : 620x215x415 mm

• Machine Cooling Mode : Air Cooled

• Tungsten Rod Diameter : 1.6-4.0mm

• Base Material : Carbon steel, Stainless steel, Low Alloy steel . Aluminum

• Switching Device : MOSFET

• Weight : 35 Kg (Approx)

Features

• Auto Protection of over-voltage and over-current

• Reliable digital inverter pulse mode AC/DC TIG welding, with HF and MMA (Stick) for constant inverter functioning

• Adjustable slop up/down, Gas pre-flow and post-flow control for maximum shielding gas protection before and after the weld

• Combination of AC and DC TIG permit deep penetration and significantly ' cut down electrode consumption

• Light and Handy for easy portability

Accessories

• Electrode Holder
• Earthing Clamp

Applications

• Automotive parts
• Sheet metal and thinner sections
• Aircraft industries
• Chemical and instrument industries
• Furniture & kitchenware
• Mechanical components
• Plant& machinery
• Maintenance and repair
• Atomic energy
• Instrument diaphragms
• Instrument industries
