• Inlet/Outlet Size: 2.5 inch (6.35 cm approximately)
• Nominal Flow Rate: 40 cubic meters per hour
• Material: Reinforced polypropylene (corrosion-resistant)
• Maximum Operating Pressure: Approx. 6 kg/cm² (85 PSI)
• Weight: Approximately 11-12 kg
• Removes sand and silt particles above 75 microns
• Suitable for agricultural and irrigation water cleaning
• Dimensions: Typical length approx. 1365 mm, diameter approx. 1112 mm (varies by specific model)
• Includes flange end or standard coupling for easy installation
• Designed for self-cleaning with simple flushing of collected particles

Features

• Removes fine sand and silt particles above 75 microns efficiently
• Uses centrifugal force for particle separation without filter media
• Durable polypropylene construction for corrosion resistance
• Nominal flow rate of 40 cubic meters per hour
• Operates under maximum pressure of around 6 kg/cm²
• Easy installation with 2.5 inch inlet and outlet connections
• Low maintenance with simple flushing of collected particles
• Protects irrigation systems by preventing clogging of downstream emitters
• Suitable for agricultural and industrial water cleaning applications
• Lightweight design, approximately 12 kg for easy handling

Applications

• Use as a primary filter to remove fine sand and silt particles above 75 microns from irrigation water.
• Install at the water source such as borewell or canal to prevent sediment clogging downstream.
• Combine with secondary screen or disc filters for enhanced purification in drip and sprinkler systems.
• Ideal for agricultural farms, horticulture, and landscape irrigation to protect emitters.
• Use in water cleaning for industrial processes requiring solids separation.
• Install inline with irrigation pipelines, ensuring easy access for drain flushing to maintain performance.
• Effective for cleaning irrigation water containing suspended dirt and sediment to improve system longevity.

Usage

• Install the filter at the water source (like borewell outlet) to remove sand and silt before water enters the irrigation system.
• Connect the 2.5 inch inlet and outlet securely with compatible pipes or fittings.
• Position the filter for easy access to the drain valve for periodic flushing of collected particles.
• Use it as a primary filter ahead of secondary screen or disc filters to improve overall filtration efficiency.
• Install in vertical or horizontal pipe layouts as per system design.
• Regularly open the drain valve to discharge settled dirt, preventing clogging and maintaining flow rate.
• Combine with drip or sprinkler irrigation systems for better crop protection and system longevity.
• Monitor pressure drop across the filter to schedule cleaning for optimal operation.
