Made in India 3 HP Single Stage Single Phase Ring Blower

Easy Returns

Quality Assurance

Trusted Delivery

After Sales Assistance

Short Description

 Ring Blower

3 HP Single Stage Single Phase

1 year Warranty

Description

Made in India 3 HP Single Stage Single Phase Ring Blower

Descriptions :

•  Cooler running NSK & TPI bearing.Precise blade and cover made of die-cast aluminum,High quality copper winding motor with IP54 and IP55 protection and insulation class F Die-cast aluminum alloy housing.
• Wide voltage and frequency.Stable working performance and energy saving
•  Dual-usage: Compressor and vacuum(blow and suction)
•  Centrifugal circulation design.High pressure and big smooth air volume,No oily odors
•  Air flow cushioning design.Low noise and low vibration
•  Compact light weight design.Longer operating life and easy installation.

Specifications :

• Product Type : Ring Blower
• Brand : Made in India
• Model : 3 HP Single Stage Phase Ring Blower
• Body Material : Aluminium
• Power : 3 HP / 2.2 KW
• Power Phase : Single Phase
• Blower Type : Turbo Blower
• Pressure : 250 mbar ( 25 kpa)
• Voltage : 220-240 V
• Air Flow Rate : 5.3 m3/min,318 m3/hr,188cfm

• Frequency : 50 HZ
• Noice Level : 70 DB
• Speed : 2800 RPM
• Weight : 32 Kg (Approx)
