Brand : Kirloskar
Kirloskar 1HP 10 Stage(4 inch) 1Ph Water Cooled Submersible Pump With CP, 256ft Head - 1.6 Year Warranty(NEO 60-1010 CP)
SKU : TI-KN-12769
MRP : ₹29400
₹21999
25% OFF!
-
1
+
678 people have viewed this recently
Get Extra ₹330 OFF on Prepaid Orders
Delivery By: Aug 5 - Aug 7
Add to Cart
Buy Now
Easy Return
& Refund
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Buyer
Protection
Short Description
Kirloskar (NEO 60-1010 CP) 1.0 HP Submersible Pump With CP
1 Phase, Water Cooled
78M Max. Head
6300 LPH Max. Discharge
1.6 Years Of Warranty
Country of origin: India
Specification
  • Brand: Kirloskar
  • Power : 1 hp
  • Weight (Approx.) : 23 kg
  • Flow Rate : 105 lpm
  • Head : 78 meter
  • Model No. : NEO 60-1010 CP
  • Product Type : Borewell Submersible Pump
  • Brand : KIRLOSKAR
  • Wattage : 0.75 kW
  • No Of Stages : 10
  • Outlet Size : 32 mm
  • Rated Voltage : 220 Volt, 50 Hz, AC Power Supply
  • Electricity Connection : Single Phase
  • Rated Current : 8.2 Amp.
  • Max. Head Range : 78 Meter (256 Feet)
  • Max. Discharge Rate : 105 LPM (6300 LPH)
  • Borewell Size : 100 mm (4 inch)
  • Cooling Type : Water Cooled
  • Insulation : B Class
  • Protection : IP 68
  • Winding Material : Copper

Material Of Construction :
  • Pump Housing : Stainless Steel
  • Pump Shaft : Stainless Steel
  • Motor Housing : Stainless Steel
  • Motor Shaft : Stainless Steel
  • Thrust Bearing : Carbon + Stainless Steel
  • Motor/Pump Bushes : Gun Metal
  • Impeller : Noryl
  • Diffuser : Noryl
  • NRV : Cast Iron
  • Suction : Cast Iron

Description
A water-cooled submersible pump is an electric pump designed to operate fully submerged in the fluid it's pumping, utilizing the surrounding water to dissipate heat from its motor. This design ensures efficient cooling and allows for continuous operation in applications like dewatering, irrigation, and water supply.

Features

 :
  • Wide Voltage Range Operability : Voltage range is 180 - 240 Volts. Protects motor from burning due to lower/higher voltage
  • High Efficiency and Energy-saving Design : Higher output, lesser power consumption
  • Dynamically Balanced Rotating Parts : Resulting in lesser vibrations and longer trouble-free operation
  • Longer and Trouble Free Life : High grade engineering materials like Graded Cast Iron Components, Stainless Steel Shaft, Noryl Impellers, Bronze Bushes, Heavy duty Carbon + SS Thrust Plate, 99.9 % pure Copper Winding Wires for longer and trouble free life.
  • Advanced Water Cooled Motors Designs : The motor is filled with potable water, protects from overheating and facilitates smoother and trouble free operation for the years.
  • Sand Fighter Designs : Innovative Sand Fighter Designs restricts the entry of sand in motors, protects the pump and motor bushes to perform well in sandy borewells and increase the pump set life.
  • CED - Cathodic Electro Deposition Coating : Better resistance against corrosion.
  • Nationwide Service Network : Easy availability of spares and prompt after sales services through nationwide company authorised service centers.

Applications

 :
  • Domestic and community water supply
  • Rural water supply
  • Gardening and small farm irrigation
  • Construction site
  • Water supplies for high rise building

Warranty :
  • 1.6 Years on site Warranty
