Brand: Neptune
Neptune HTP-22 (Silver), 20-45 Bar HTP Spray Pump Without Motor For Cleaning & Agricultural Spray
SKU: SD-NP-20224322
6 people have bought this recently
Delivery By: Dec 17 - Dec 19
MRP : ₹5500 ₹3690
33% OFF!
6 people have bought this recently Delivery By: Dec 17 - Dec 19 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹3690 (Including GST)
MRP : ₹5500
33% OFF!
Get Extra ₹55 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
Neptune HTP 22 Power Sprayer (Silver)
45 Bar Max. Pressure
22 LPM Max. Discharge
All The Required Accessories are Included
Country of origin: China
Specifications
- Brand: Neptune
- Weight (Approx.) : 7.2 kg
- Model No. : Silver
- HTP Type : HTP 22
- Output Pressure : 20-45 kg/cm² (20-45 Bar)
- Required Motor Power : 1.5 to 2 HP (1.1-1.5 kW)
- Speed : 800 - 1200 RPM
- Max Flow : 14-22 L / min
- Max Pressure : 25-35 Bar
- Pump Oil Capacity : 700 ml (20W40)
- Suction Volume : 14-22 LPM
- Plunger : 3x22
Note : Colour of the Product May vary
Description
The Neptune HTP-22 (Silver) is a high-pressure, robust HTP spray pump designed for agricultural spraying and various cleaning applications. Operating at pressures between 20-45 Bar and delivering a flow rate of 14-22 liters per minute, it ensures powerful, efficient spraying performance. The pump features a durable cast body with excellent heat absorption to maintain performance under heavy use. Compatible with 1.5 to 2 HP motors, it integrates smoothly into existing motor setups. This model includes complete accessories like suction hose, overflow hose, pulley, and filter for easy installation. Ideal for spraying pesticides, herbicides, and fungicides on farms and orchards, as well as vehicle washing and industrial cleaning, the HTP-22 offers versatility and reliability without the weight of a built-in motor.
Features
:- Operates at 20-45 Bar pressure
- Flow rate of 14-22 L/min
- Durable cast body with heat absorption
- Compatible with 1.5 to 2 HP motors
- Includes suction hose, overflow hose, pulley
- Easy to install and maintain
Accessories
:- Suction Hose Pipe
- Overflow Hose Pipe
- Pulley
- Filter
- Tool Kit & Washer
- User Manual
Applications
:- Agricultural spraying (pesticides, herbicides)
- Fungicide and fertilizer spraying
- Vehicle cleaning (cars, bikes)
- Industrial pressure cleaning
- Orchard and plantation spraying
- General purpose high-pressure fluid transfer
Usage
:- Mount the motor with suitable engine or electric motor
- Attach the inlet pipe, overflow pipe, and hose pipe.
- Connect with electricity if mounted with motor or pour the fuel in fuel tank and the engine oil in engine oil chamber accordingly and start the engine if mounted with an engine
- Be sure about safety precautions.
- Do your work as per your needs.
Always refer to the manufacturer's instructions and safety guidelines when operating an HTP pump without a motor.
