Brand: Generic (Imported)
Jeevan Gold Premium HTP 22 with Robust 6.5 HP Engine | Suitable for High Pressure Spraying
SKU: TI-JG-44171
Delivery By: Dec 10 - Dec 12
MRP : ₹17600 ₹9790
44% OFF!
Delivery By: Dec 10 - Dec 12 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹9790 (Including GST)
MRP : ₹17600
44% OFF!
Get Extra ₹147 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
Jeevan Gold premium HTP 22
Comes with Robust 6.5 HP Engine
Suitable for High-Pressure Spraying
Country of origin: China
Specifications
- Brand: Generic (Imported)
- Weight (Approx.) : 24.5 kg
Pump Specification :
- HTP Pump Model : 22
- Pump RPM : 800-1200
- Output Pressure : 10-40 kg/cm2
- Suction Volume : 13-22 L/min
- Body Material : Aluminum Die Cast
- Pump Material : Brass Coated Cast Iron
- Pulley Size : 7 Inch (17.7 cm)
- No. of Cock (Outlet Connections) : 2
- Suitable Hose Pipe Diameter : 8.5 MM & 10 MM
- No. of Piston : 3
- Pump Oil Capacity : 700 ml (20W40)
- Max Hose Pipe Can Be Connect : 50 to 100 meter
Engine Specification :
- Rated Power : 6.5 HP
- Displacement : 196 cc
- Engine Type : 4 - Stroke, Air cooled
- Fuel Used : Petrol
- Fuel Tank : 3.6 Liter (Approx.)
- Engine Oil Capacity : 600 ML (20W40)
- Fuel Consumption : 700-900 ml/hour (Approx.)
Description
Toolsvilla is proud to offer the Jeevan Gold Premium HTP 22, engineered for superior performance and durability. This high-pressure sprayer is equipped with a robust 6.5 HP engine, ensuring reliable and consistent operation for demanding applications. The HTP 22 is specifically designed for high-pressure spraying, making it ideal for agricultural, industrial, and commercial use. Experience enhanced efficiency and coverage with this premium-grade sprayer, a valuable addition to any professional toolkit.
Features
:- Robust Engine
- Highly Efficient
- High Pressure
- Easy to Use
- Heavy-Duty Build Quality
- Long-Lasting & Durable
Accessories
:- 1.5 Meter Suction Pipe
- 1.5 Meter Overflow Pipe
- Filter
- 2 Belt For Pully
- Tool Kit
- Oil Seal Ring
- Spray Gun
Applications
:- Used for high-pressure spraying, cleaning, etc.
Usage
:- Attach the inlet pipe, overflow pipe, and hose pipe.
- Pour fuel in the fuel tank accordingly, & Pour the engine oil in the engine oil chamber separately.
- Be sure about safety precautions.
- Start the engine and do your work as per your needs.
