HPM 2.8 KVA Recoil Start Single Phase Portable Petrol Generator (GE-3000P)

Easy Returns

Quality Assurance

Trusted Delivery

After Sales Assistance

Short Description

HPM 2.8 KVA Single Phase Portable Petrol Generator

Recoil Start

Petrol Run & LPG(Optional)

11 Amp Rated Current For Generator

12 Amp Max. Current Capacity For Alternator

6.5 HP Max. Power For Engine

Description

HPM 2.8 KVA Recoil Start Single Phase Portable Petrol Generator (GE-3000P)

Description :

• This light weight & powerful portable petrol generator Genset With Simple Design & Having Low Maintenance & Long Life, It is used for Homes, Shops Photo Copier Commercial Or Field Jobs.

Features :

• GE – 3000 P/PS – Petrol & LPG Portable Generators Series. (Single Phase) Export Model

• 2.8 KVA Genset With Simple Design & Having Low Maintenance & Long Life.

• Recoil Start

Applications :

• General Purpose Use For Homes, Shops Photo Copier Commercial Use Or Field Jobs For Running Electrical Loads of 2.5 KVA Capacity.

Specifications :

• Model No: GE-3000 P
• Product Type: Petrol Generator
• Brand: HPM
• Dimensions (LxWxH) : 630x500x600 mm

• Weight : 49 Kg (Approx.)


Generator :

• Max AC. Output : 2800 VA
• Rated AC. Output : 2500 VA
• Rated Current Amps: 11
• NFB Amps: 11
• AC. Voltage at Rated Load : 225 Volts ± 10 Volts, 50 Hz, Single Phase
• AC. Voltage at No Load : N/A


Alternator :

• Alternator Max. Current Capacity : 12 Amps
• Alternator : Self-Excitation & Constant Voltage (With AVR), THD ≤ 25%

Engine :

• Engine Model : HM170PY
• Type : OHV25° Inclined, Single Cylinder, 4 Strokes, S.I, Forced Air Cooling
• Maximum Power: 6.5 HP @ 3600
• Displacement : 208 cc

• Bore x Stroke : 70 x 54 mm
• Starting System : Recoil Start
• Fuel : Petrol + LPG (Optional)
• Fuel Tank Capacity Petrol : 20.5 Ltr
• Fuel Consumption Petrol : 1.3 Ltr/hr, LPG 750 gm /hr
• Lube. Oil Capacity : 600 ml

• Lubricating Oil Consumption : 2.5 gm/Hr
• Sound level (Db) (from 1 meter) : <86Db

Panel And Other Standard Features :

• Voltmeter : Analogue
• Digital Hour Meter : No
• Oil Alert System : Yes
• LPG/ Gas Fuel Compatibility : Yes
• AMF Panel Auto & Remote Start Compatibility : No
• Fuel Level Gauge : Yes
• Overload Protection (NFB) : Yes
• Costar Wheels : Optional (Wheels)
• Gross weight-KG : 49 KG
