Brand: HPM
HPM 3.2 KVA Recoil and Self Start Single Phase Petrol Generator With Battery (GE-3500 RS)
SKU: DK-GS-1898
3082 people have viewed this recently
Delivery By: Dec 25 - Dec 27
MRP : ₹85000 ₹67900
20% OFF!
3082 people have viewed this recently Delivery By: Dec 25 - Dec 27 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹67900 (Including GST)
MRP : ₹85000
20% OFF!
Get Extra ₹1,019 OFF on Prepaid Orders
Short Description
HPM 3.2 KVA Single Phase Petrol Generator With Battery
Recoil and Self Start
12 Amp Rated Current
16 Amp Max. Current Capacity For Alternator
6.5 HP Max. Power For Engine & 3600 RPM Speed
Petrol + LPG (Optional) Use For Fuel
Country of origin: India
Specifications
- Brand: HPM
- Weight (Approx.) : 43.5 kg
- Fuel Used : Petrol
- Fuel Consumption : 1 l/hr
- Model No. : GE 3500 RS (12 Amps)(With Battery)
- Voltage Supply : 220 V, 50 Hz
- Phase : Single Phase
Generator :
- Max. AC Output : 3.2 KVA
- Rated AC Output : 3 KVA
- Rated Current : 13 Amp
- NFB : 13 Amp
- AC. Voltage at Rated Load : 220 Volts ± 10 Volt 50 Hz, Single Phase
- AC. Voltage at No Load : 250 Volts ± 5 Volt
Alternator :
- Brushless, Rare Earth Magnetic Rotor, THD 5% Pure sine wave
- Max. Current Capacity : 16 Amp
Engine :
- Model : HM170P
- Type : OHV25° Inclined, single cylinder, 4 strokes, S.I, Forced air cooling
- Max. Power : 6.5 HP
- Speed : 3600 RPM
- Displacement : 223 cc
- Bore x Stroke : 70 x 58 mm
- Starting System : Recoil Start & Self Start
- Fuel Tank Capacity : Petrol 20.5 Litres
- Fuel Consumption : 1.3 Ltr/Hr (Petrol)
- Lube. Oil Capacity : 600 ml
- Lubricating Oil Consumption : 2.5 gm/hr
- Continuous Running Time : 16 Hrs. With One Filling
- Sound Level (from 1 meter) : < 86 Db
Panel And Other Standard Features :
- Voltmeter : Yes (Analogue)
- Digital Hour Meter : No
- Oil Alert System : Yes
- AMF Panel Auto & Remote Start Compatibility : No
- Fuel Level Gauge : Yes
- Overload Protection (NFB) : Yes
Battery Specifications :
- 12 Volt, 9 Ah
Description
Petrol Generators are those power sources that run their engines on petrol. The chemical energy of petrol is transformed into mechanical energy by petrol engines.
Features
:- This is a very Light Weight & Powerful 3.2 KVA Portable Petrol Generator.
- Suitable to run 1 Ton Air Conditioners, Submersible Pump, Deep Freezers, Inductive & Motor Loads.
- Pure sine wave THD<5%, Suitable for sensitive electronic equipment’s.
- Very high over loading capacity.
Accessories
:- Owner Manual 1 pcs
- Funnel 1 pcs
- Screw Driver 1 pcs
- Spanner 1 pcs
- Three Pin Plug 1 pcs
Applications
:- Low Priced & Economical Generator, Best for institutional / Bulk order Supplies.
- Very much Suitable for Industrial & Commercial due to ability for Overloading.
- Running Grinders for Rail Track Maintenance, Sweet Shops, Small Restaurants.
