Diesel operated 5.5 kVA Silent Generator, Single phase
Sound Level <75Db, 12V Battery
Self Start + AMF Compatible
Brushless REM Alternator
4 Stroke Engine
Description
HPM 5.5 KVA Single phase Diesel Silent Generator with Battery (GE 7000DS)
Description :
Composite materials are used in the generator enclosure of silent diesel generators. They are typically thick layers of dense material that reflect sound energy back into the enclosure. Additionally, they employ porous, soft materials that collect sound energy and turn it into heat.
Features :
A Beautiful 5.5 KVA Portable Diesel Generator,
Pure sine wave THD<2%, Suitable for sensitive electronic equipment’s
Very high over loading capacity.
Auto shut off if engine oil is low
Auto shut off if no diesel in tank
AMF Panel Compatible (can start and stop itself, Auto load transfer & all time battery charging) (Optional)
Applications :
Runs One 1.5 Ton Air Conditioner + Other Loads.
Most Suitable for running Air Conditioners, Submersible Pump, Deep Freezers, Inductive & Motor Loads, Industrial Loads.
A Versatile Generator, suitable for all type applications, Household, Offices, Banks, ATM, Institutes, Nursing Homes, Restaurants & Industrial Applications etc.
Specifications :
Model No. : GE-7000 DS
Product Type : Diesel Generator with Battery
Brand : HPM
Generator :
Max AC. Output VA : 6500
Rated AC. Output VA : 5800
Rated Current Amps: 26
NFB Amps : 27
AC. Voltage On Laptop Mode : 230 Volts ± 10 Volts, 50 Hz, Single Phase
AC. Voltage On Power Mode (No Load) : 250 Volts ± 5 Volts
Alternator :
Max. Current capacity : 36 Amps
Brushless, Rare Earth Magnetic Rotor, THD ≤ 2 %, Pure Sine Wave
Engine :
Model : TP186F
Type : 4-Stroke, OHV, Vertical, Single Cylinder, Direct Injection
Bore x Stroke : 86*72 mm
Displacement : 418cc
Starting System : Self-Start
Fuel : Diesel
Fuel Tank Capacity : 15.5 Ltrs.
Fuel Consumption : 1.25 Ltr./hr
Lube. Oil Capacity : 1650 ml.
Lubricating Oil Consumption : 4.3 gm./Hr.
Sound level (Db) : <75 Db
Panel And Other Standard Features :
Voltmeter : Digital
Digital Hour Meter : Yes
Oil Alert System : Yes
Diesel Alert System : Yes
Cooling Fan Indicator : No
AMF Panel Auto & Remote Start Compatibility : Yes
Fuel Level Gauge : Yes
Overload Protection (NFB) : Yes
Costar Wheels : Yes
Gross weight-KG : 175 KG
Packing :
Dimension LxWxH (mm) : 1030x520x780 mm
Battery Specification : 12 Volt 35 Ah Size =190×120×225 (L×W×H)
