HPM 3 KVA Recoil & Self Start Diesel Operated Silent Generator (GE 3200DS)

Easy Returns

Quality Assurance

Trusted Delivery

After Sales Assistance

Short Description

HPM 3 KVA Diesel Operated Silent Generator With Battery

Recoil & Self Start

Brushless, Rare Earth Magnetic Rotor & 24 Amp Max. Current Capacity Alternator

4 Stroke, 208 cc Engine

12 Volt 35 Ah Battery

Description

HPM 3 KVA Recoil & Self Start Diesel Operated Silent Generator With Battery (GE 3200DS)

Description :

• A quiet portable diesel generator, which combines a diesel engine with an electric generator and is available in many physical and electrical configurations, is frequently used as a backup source of electricity in commercial and residential buildings.

Features :

• Portable and light weight Diesel Genset
• Running cost is the lowest and very fuel Efficient, so produce electricity at very economical rates
• Run 0.75 ton Air Conditioners

Applications :

• Very useful all-purpose portable genset for small electric loads up to 2.5 KVA also useful for running light machinery, motor and inductive loads like 0.75 Ton AC, Deep Freezer etc.

Specifications:

• Model No.: SILENT GE 3200DS
• Product Type: Diesel Generator
• Brand: HPM
• Dimensions (L x W x H) : 1000 x 470 x 710 mm
• Weight : 90 Kg (Approx.)

Generator :

• Max AC. Output : 3000 VA
• Rated AC. Output  : 2600VA
• Rated Current Amps : 11.7
• NFB Amps : 12
• AC. Voltage On Laptop Mode : 230 Volts ± 10 Volts, 50 Hz, Single Phase
• AC. Voltage On Power Mode (No Load) : 250 Volts ± 5 Volts

Alternator :

• Alternator : Brushless, Rare Earth Magnetic Rotor, THD ≤ 2 %, Pure Sine Wave
• Alternator Max. Current Capacity : 24 Amps

Engine :

• Model : TP170F
• Type : 4-Stroke, OHV, Single Cylinder, Direct Injection, Swirl Chamber, Inclined type
• Bore x Stroke : 70*54 mm
• Displacement : 208cc
• Starting System : Recoil Start and Self Start
• Fuel : Diesel
• Fuel Tank Capacity : 14.5 Ltrs.
• Fuel Consumption : 0.7 Ltr./hr.
• Lube. Oil Capacity : 700 ml.
• Lubricating Oil Consumption : 2.8 gm./Hr.
• Sound level (Db) : <75DB

Panel And Other Standard Features :

• Voltmeter : Analogue
• Digital Hour Meter : No
• Oil Alert System : Yes
• Diesel Alert System : Yes
• Cooling Fan Indicator : Yes
• AMF Panel Auto & Remote Start Compatibility : No
• Fuel Level Gauge : Yes
• Overload Protection (NFB) : Yes
• Costar Wheels : Yes

Battery Specifications :

• 12 Volt 35 Ah
