HPM 5 KVA Recoil and Self Start Diesel Operated Silent Generator With Battery (SILENT BDS 5000)

Easy Returns

Quality Assurance

Trusted Delivery

After Sales Assistance

Short Description

HPM 5 KVA Diesel Operated Silent Generator With Battery

Recoil and Self Start

18.3 Amp Rated Current For Generator

Brushless Alternator With 32 Amps Max. Current Capacity

20 Ltr. Fuel Tank Capacity & 4 Stroke Engine

Description

HPM 5 KVA Recoil and Self Start Diesel Operated Silent Generator With Battery (SILENT BDS 5000)

Description :

• Quiet diesel generators utilize composite materials in a generator housing. They are typically thick layers of dense material that reflect sound energy back into the container. Moreover, they employ porous, soft materials that collect sound energy and turn it into heat.


Features :

• Pure sine wave THD<2%, Suitable for sensitive electronic equipment’s

• Very high over loading capacity.
• Auto shut off if engine oil is low
• Auto shut off if no diesel in tank
• High Temperature Indicator & Alarm
• AMF Panel Compatible (can start and stop itself, Auto load transfer & all time battery charging) (Optional)
• Very low noise Portable Diesel Generator, fuel efficient, produces electricity at very economical rates.

• World’s highest fuel efficient Portable D.G. Set.

Applications :

• Suitable to run 1.5 Ton Air Conditioners, Submersible Pump, Deep Freezers, Inductive & Motor Loads.
• Wide usage from home, offices, commercial, small Banks & ATMS, industrial, institutional., field job etc.

Specifications :

• Model No. : SILENT BDS 5000
• Product Type : Diesel Silent Generator
• Brand : HPM
• Dimension (LxWxH) : 1195 x 525 x 710 mm

• Weight : 150 Kg (Approx.)


Generator :

• Maximum Output : 5000 VA
• Rated AC. Output : 4200 VA
• Rated Current : 18.3 Amps
• NFB : 19 Amps
• AC. Voltage On Laptop Mode: 230 Volts ± 10 Volts,50 Hz, Single Phase
• AC. Voltage On Power Mode(No Load): 250 ± 5 Volts

Alternator :

• Alternator Max. Current Capacity : 32 Amps
• Alternator: Brushless, Rare Earth Magnetic Rotor, THD ≤ 2%, Pure Sine Wave

Engine :

• Engine Model : TP176F
• Type : 4-Stroke, OHV, Single Cylinder, Direct Injection, Swirl Chamber, Inclined type
• Bore x Stroke : 76 x 68 mm
• Displacement : 308 cc

• Starting System : Recoil Start & Self Start
• Fuel Used : Diesel
• Fuel Tank Capacity : 20 Liters
• Fuel Consumption Ltr./Hr. : 1.0 Ltr./hr.
• Lube. Oil Capacity : 900 ml.
• Lubricating Oil Consumption : 4.1 gm./Hr.
• Sound level(Db) : <75DB

Panel And Other Standard Features :

• Voltmeter : Digital
• Digital Hour Meter : Yes
• Oil Alert System : Yes
• Diesel Alert System : Yes
• Cooling Fan Indicator : Yes
• AMF Panel Auto & Remote Start Compatibility : Yes
• Fuel Level Gauge : Yes
• Overload Protection (NFB) : Yes
• Costar Wheels : Yes

Battery Specification :

• 12 Volt 35 Ah
