Brand: Generic (Imported)
Solax X1-MINI-4.0K-G4 Solar Off Grid Inverters, Commercial Applications, Homes And Small Shops
SKU: TI-SX-63943
Delivery By: Feb 26 - Feb 28
MRP : ₹35900 ₹27600
23% OFF!
Delivery By: Feb 26 - Feb 28 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹27600 (Including GST)
MRP : ₹35900
23% OFF!
Get Extra ₹414 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
Solax X1-MINI-4.0K-G4 Inverters
Solar Off Grid Inverters
Commercial Applications, Homes And Small Shops
Country of origin: China
Specifications
- Brand: Generic (Imported)
- Weight (Approx.) : 7 kg
- Model Name : X1-MINI-4.0K-G4
DC INPUT :
- Max. PV array input power [Wp] : 8000
- Max. PV input voltage [V] : 550
- Startup voltage [V] : 50
- Nominal input voltage [V] : 360
- MPP tracker voltage range [V] : 40-550
- No. of MPP trackers / Strings per MPP tracker : 1/1
- Max. PV input current [A] : 16
- Isc PV Array Short Circuit current [A] : 22
AC OUTPUT :
- Rated AC output power [W] : 4000
- Rated AC output current [A] : 17.4
- Max. AC output apparent power [VA] : 4000
- Max. AC output current [A] : 20
- Nominal AC voltage/AC voltage range [V] : 220/230/240 ; 90-290
- Nominal AC frequency/AC frequency range [Hz] : 50/60 ; ±5
- Power Factor range : 0.8 leading~0.8 lagging
- THDi (Rated power) [%] : <3
SYSTEM DATA :
- Max. eciency [%] : 98
- Euro. eciency [%] : 97
- Standby consumption [W] @Night : <1
- Ingress protection : IP66
- Protection class : Class I
- Over voltage category : II (DC),III (AC)
- Operating ambient temperature range [°C] : -25~60
- Max. operation altitude [m] : <4000
- Humidity [%] : 0-100
- Typical noise emission [dB] : 25
- Storage temperature [°C] : -30~70
- Dimensions (W×H×D) [mm] : 290x206x120 mm
- Cooling concept : Natural cooling
- Communication interfaces : USB/RS485/DRM, Optional: Meter/CT
- Optional monitoring dongle : Pocket WiFi/LAN/4G
- Display : 2 x LED + LCD(16 x 2) / APP
Description
The SolaX X1-MINI-4.0K-G4 represents the latest generation (G4) of compact power conversion. It is designed to maximize energy harvest from limited roof spaces. With a startup voltage of only 50V and an efficiency rating of 98%, it begins generating power earlier in the morning and continues later into the evening than many competitors. Its sleek, fan-less design ensures silent operation, making it ideal for indoor installations in shops or homes.
Features
:- High Efficiency: Boasts a maximum efficiency of 98.0% with an ultra-low start-up voltage of 50V.
- Powerful Performance: Supports 200% PV oversizing and a 16A DC input current, making it compatible with modern high-power solar modules.
- Smart Management: Features a built-in export power control function and supports smart load management (e.g., heat pumps and EV chargers).
- Compact & Robust: Weighing only 5.5 kg and smaller than a sheet of paper, it carries an IP66 rating for durability in outdoor environments.
- Advanced Safety: Includes Type II Surge Protection (SPD) on both AC and DC sides, optional AFCI (Arc-fault circuit interrupter), and global MPP tracking to optimize shade performance.
- Connectivity: 10-second data refresh rates via SolaXCloud and support for parallel operation of up to five inverters via Modbus.
