LuxMed Steam Sterilizer Controller Jumbo LCD Menu Control Inbuilt Cycle Vacuum Pump Control Grand

Microprocessor-based steam sterilizer controller
Controls dual PT-100 inputs
Manages dedicated vacuum pump relays

The LuxMed Steam Sterilizer Controller (Model: Grand) is an advanced, high-capacity automation solution engineered for absolute precision in steam sterilization processes up to 330 Degrees Celsius. Constructed with a durable white plastic enclosure, this controller features a clear 20x4 Jumbo LCD screen paired with flexible ON/OFF and T.P. control types. The system simultaneously regulates two PT-100 temperature sensors (one for the boiler and one for the chamber) along with one dedicated pressure transmitter input for direct chamber pressure display. Built for comprehensive system integration, it features built-in serialization cycles, a dedicated vacuum pump controller, a low water sensor, Bowie & Dick equipment testing support, and relays for handling 3, 4, 5, or 6 solenoid valves. Technicians can fully customize parameters via the menu layout including user-settable purging ranges, sterilization times, post-sterilization drying times, and explicit boiler controls, with complete tracking logged via selectable communication outputs (Printer, CFR/PC, USB Storage).
