Kisan Gold (CKG-S100) HTP 100 Power Sprayer Pump for Agricultural Irrigation & Commercial Field Spraying 3-Piston Design

Brand: Generic (Imported)

Kisan Gold (CKG-S100) HTP 100 Power Sprayer Pump for Agricultural Irrigation & Commercial Field Spraying 3-Piston Design

Name: Kisan Gold (CKG-S100) HTP 100 Power Sprayer Pump for Agricultural Irrigation & Commercial Field Spraying 3-Piston Design
Brand: Generic (Imported)
SKU: TI-HH-51840
Price: 11350 INR
Availability: InStock
Rating: 5.00 (1 reviews)

SKU: TI-HH-51840

MRP : ₹13500 ₹11350

16% OFF!

Get Extra ₹170 OFF on Prepaid Orders

Estimated Delivery By: Jul 26 - Jul 28

Easy Return
& Refund

Quality
Assurance

Trusted
Delivery

After Sales
Assistance

Buyer
Protection

₹11350 (Including GST)

MRP : ₹13500

16% OFF!

Get Extra ₹170 OFF on Prepaid Orders

QTY :

Add to Cart

Buy Now

Kisan Gold (CKG-S100) HTP 100 Power Sprayer Pump

For Agricultural Irrigation & Commercial Field Spraying 3-Piston Design

Country of origin: China

Brand: Generic (Imported)
Weight (Approx.) : 23 kg

Model : Kisan Gold HTP 100 (CKG-S100)
Number of Pistons : 3
Piston Diameter x Stroke : 34 x 26 mm
Required Motor Power : 3 - 7 HP
Operational Speed Range : 600 - 800 RPM
Suction Flow Rate (LPM) : 60 - 80 Liters Per Minute
Pressure Range : 15 - 35 kgf/cm²
Drive Pulley Size : 4 Inch
Physical Dimensions : 39 x 30 x 34 cm

Maximize your agricultural productivity with the Kisan Gold HTP 100 (Model: CKG-S100), a commercial-grade horizontal triplex plunger pump built for heavy-duty spraying operations. Driven by a powerful 3-Piston system with a precision-engineered 34x26 mm diameter-to-stroke setup, this pump provides relentless power and consistent pressure delivery. Designed to run smoothly between 600–800 RPM, it significantly reduces operational vibration and component wear while churning out a substantial water displacement capacity of 60–80 Liters Per Minute (LPM). Whether you are running an expansive orchard irrigation setup or handling aggressive commercial chemical spraying, this system delivers an easily adjustable output between 15–35 kgf/cm². It pairs perfectly with electric motors or engines ranging from 3–7 HP, making it highly adaptable to your existing equipment setups. Encased in a sturdy, compact space-saving body measuring just 39 x 30 x 34 cm, it offers an optimal balance of portable mobility and unwavering structural strength for long farm workloads.

Features

Triplex Piston Delivery: The dedicated three-piston architecture eliminates pressure surges, providing an ultra-smooth, uniform stream of fluid.
Heavy Duty Cast Iron Build: Crafted with premium-grade metals that actively resist corrosive chemical mixtures and heavy field wear.
Balanced Drive System: Outfitted with a durable 4-inch pulley that maximizes rotational energy from the motor while reducing power loss.
Compact Footprint: The space-saving 39 x 30 x 34 cm body integrates effortlessly onto mobile spray carts, tractor attachments, or stationary platforms.
Low Maintenance Design: Engineered with easily accessible pressure valves and grease cups to ensure routine servicing takes only minutes.

Applications

Orchard Fruit Spraying: Delivers the necessary pressure to reach high into mango, orange, and apple orchard tree canopies.
Row Crop Pest Control: Ideal for running multi-nozzle spray booms across cotton, rice, and vegetable plantations.
Tractor & Equipment Cleaning: Provides a powerful water stream perfect for blasting caked-on mud off farm machinery and fleets.
Livestock Barn Sanitization: Excellent for pressure-washing and thoroughly disinfecting dairy farms, poultry coops, and stables.
Open Field Irrigation: Functions as a reliable high-flow water transfer system for localized agricultural irrigation channels.
