Volley HTP 75 (CB-S75) 3-Piston 60-80 LPM Power Sprayer Pump

For Agricultural Spraying and Commercial Car Washing

Country of origin: China

Brand: Generic (Imported)
Weight (Approx.) : 23 kg

Model : (CB-S75)
HTP : 75
Required Motor Power : 3-7 HP
Piston Configuration : 3 Plungers
Piston Diameter x Stroke : 34 mm x 26 mm
Operational RPM : 600 - 800 RPM
Suction Rate (LPM) : 60 - 80 Liters Per Minute
Working Pressure Range : 15 - 35 kgf/cm²
Pulley Size : 4 Inches
Product Dimensions : 39 x 30 x 34 cm

The Volley HTP 75 (CB-S75) High Pressure Power Sprayer Pump is a commercial-grade, high-efficiency triplex plunger pump designed explicitly for demanding agricultural and light industrial applications. Engineered with a powerful 3 piston system featuring a 34mm diameter and 26mm stroke, this robust pump delivers a steady, consistent suction rate of 60 to 80 Liters Per Minute (LPM). Operating optimally within a smooth 600–800 RPM range, it generates adjustable, customizable pressure from 15 to 35 kgf/cm², allowing you to effortlessly switch between wide area misting and concentrated high pressure jet cleaning. Built with space-saving 39 x 30 x 34 cm dimensions, the CB-S75 provides exceptional placement flexibility on mobile spray carts, tractors, or wall mounts without sacrificing mechanical output. Completed with a pre-fit, balanced 4 inch pulley, it integrates seamlessly into belt driven setups powered by electric motors or diesel engines for reliable, long-term performance.

Features

Vibration Free Triplex Plunger Build: The integrated three-piston architecture ensures a steady, pulse-free fluid delivery, minimizing line shaking.
Customizable Pressure Output: Provides a flexible 15–35 kgf/cm² pressure range, enabling operators to fine-tune settings for either delicate plant protection or hard-surface blasting.
Optimized RPM Configuration: Designed to perform at 600–800 RPM, which optimizes power draw from matching electric motors or engines, cutting overall utility costs.
Corrosion-Resistant Structural Alloys: Manufactured using heavy-duty cast alloys engineered to withstand harsh agricultural chemicals, fertilizers, and prolonged water contact.
Universal Pulley Compatibility: Features a standard 4-inch drive pulley that easily couples with standard A or B-section belts for effortless power transmission.

Applications

Farmland and Field Crop Spraying: Perfect for large-scale, uniform distribution of pesticides, liquid fertilizers, and plant growth regulators over row crops.
Commercial Vehicle Jet Washing: Provides the ideal volume-to-pressure balance for cleaning motorbikes, cars, and commercial transport vehicles at local garage bays.
Orchard Mist Spraying: Delivers dense, high-reach mist clouds necessary for protective canopy coverage in orchards, vineyards, and plant nurseries.
Livestock Facility and Barn Sanitation: Enables rapid high-volume washing and disinfecting of cattle sheds, poultry houses, and milking parlors.
General Rural Water Transfer: Suitable for rural water distribution, filling overhead storage tanks, and managing micro irrigation systems.
