Volley HTP 100 (Model: CB-S100) 3-7 HP Triplex Plunger Pump for Agricultural Spraying and Commercial Car Washing

Brand: Generic (Imported)

Volley HTP 100 (Model: CB-S100) 3-7 HP Triplex Plunger Pump for Agricultural Spraying and Commercial Car Washing

Name: Volley HTP 100 (Model: CB-S100) 3-7 HP Triplex Plunger Pump for Agricultural Spraying and Commercial Car Washing
Brand: Generic (Imported)
SKU: TI-HH-51827
Price: 11350 INR
Availability: InStock
Rating: 5.00 (1 reviews)

SKU: TI-HH-51827

MRP : ₹13500 ₹11350

16% OFF!

693 people have viewed this recently

Get Extra ₹170 OFF on Prepaid Orders

Estimated Delivery By: Jul 25 - Jul 27

Easy Return
& Refund

Quality
Assurance

Trusted
Delivery

After Sales
Assistance

Buyer
Protection

₹11350 (Including GST)

MRP : ₹13500

16% OFF!

Get Extra ₹170 OFF on Prepaid Orders

QTY :

Add to Cart

Buy Now

Volley HTP 100 (Model: CB-S100) 3-7 HP Triplex Plunger Pump

For Agricultural Spraying and Commercial Car Washing

Country of origin: China

Brand: Generic (Imported)
Weight (Approx.) : 23 kg

Model Number : CB-S100
HTP : 100
Piston Type (Qty x Dia x Stroke) : 3 x 34 x 26 mm
Operational RPM Range : 600 - 800 RPM
Required Motor Power : 3 - 7 HP
Suction Flow Rate : 60 - 80 Liters Per Minute (LPM)
Working Pressure Range : 15 - 35 kgf/cm²
Drive Pulley Size : 4 Inch
Pump Dimensions : 45 x 34 x 42.5 cm

The Volley HTP 100 (Model: CB-S100) is a commercial-grade, horizontal triplex plunger pump engineered for high-performance operations across agricultural and industrial landscapes. Driven by a robust 3 X 34 X 26 piston configuration, this high pressure power sprayer operates efficiently within a 600-800 RPM range. Designed to pair seamlessly with 3-7 HP electric motors or engine setups, it delivers an impressive suction capacity of 60-80 liters per minute (LPM). Whether you are tackling large scale farmland crop spraying or managing a demanding commercial vehicle washing bay, its adaptable 15-35 kgf/cm² pressure range guarantees thorough, deeply penetrating coverage. Outfitted with a durable 4-inch pulley and built to last, the compact 45 x 34 x 42.5 cm frame ensures stable, vibrating-minimized mounting for extended operating hours.

Features

Triple Piston Mechanism: The precision-engineered 3-piston setup ensures an ultra-smooth fluid flow with minimal pulsation.
Rugged Construction: Built from premium, corrosion-resistant alloy materials capable of withstanding harsh agrochemicals and heavy daily water flow.
Optimized RPM Efficiency: Operates at a steady 600-800 RPM to balance peak hydraulic performance with low mechanical wear and tear.
Space-Saving Footprint: Compact physical dimensions (45 x 34 x 42.5 cm) allow it to fit easily onto portable trolley sprayers, tractors, or tight wash bay stations.
Industrial Grade Sealing: Advanced pressure seals drastically prevent fluid leakage, extending the overall lifecycle of internal components.

Applications

Orchard & Crop Spraying: Perfect for large-scale agricultural operations to spray pesticides, liquid fertilizers, and nutrients uniformly over tall trees and vast farmlands.
Commercial Car Washing Bays: Provides the ideal high-flow, high-pressure stream required to quickly strip away mud, grease, and road grime from trucks, tractors, and cars.
Industrial High-Pressure Cleaning: Excellent for washing down heavy industrial machinery, livestock sheds, dairy barns, and factory floors to maintain strict hygiene standards.
Construction Site Dust Suppression: Regularly utilized to power water misting setups or curing processes on concrete structures and dusty construction zones.
Public Sanitation & Disinfection: Highly effective for municipal sanitization drives, allowing quick and wide-reaching spraying of disinfectants in outdoor community areas.
