Veto (CV-S100GF) HTP 100 Power Sprayer Pump with 60-80 LPM Suction for Agricultural Spraying 3-Piston with 4-Inch Pulley

Brand: Generic (Imported)

Veto (CV-S100GF) HTP 100 Power Sprayer Pump with 60-80 LPM Suction for Agricultural Spraying 3-Piston with 4-Inch Pulley

Name: Veto (CV-S100GF) HTP 100 Power Sprayer Pump with 60-80 LPM Suction for Agricultural Spraying 3-Piston with 4-Inch Pulley
Brand: Generic (Imported)
SKU: TI-HH-51872
Price: 14300 INR
Availability: InStock
Rating: 5.00 (1 reviews)

SKU: TI-HH-51872

MRP : ₹19000 ₹14300

25% OFF!

Get Extra ₹215 OFF on Prepaid Orders

Estimated Delivery By: Jul 25 - Jul 27

Easy Return
& Refund

Quality
Assurance

Trusted
Delivery

After Sales
Assistance

Buyer
Protection

₹14300 (Including GST)

MRP : ₹19000

25% OFF!

Get Extra ₹215 OFF on Prepaid Orders

QTY :

Add to Cart

Buy Now

Veto (CV-S100GF) HTP 100 Power Sprayer Pump

With 60-80 LPM Suction

For Agricultural Spraying 3-Piston with 4-Inch Pulley

Country of origin: China

Brand: Generic (Imported)
Weight (Approx.) : 23 kg

Model Number : CV - S100GF
Required Motor Power : 3-7 HP
HTP : 100
Piston Configuration : 3 Plungers / Pistons
Piston Dimensions (Diameter x Stroke) : 34 mm x 26 mm
Operational Speed Range : 600 - 800 RPM
Suction Flow Rate (LPM) : 60 - 80 Liters Per Minute
Working Pressure Range : 15 - 35 kgf/cm²
Drive Pulley Size : 4 Inches
Product Dimensions : 45 x 34 x 42.5 cm

The Veto CV-S100GF (HTP 100) is an industrial-grade, heavy-duty Horizontal Triplex Plunger (HTP) power sprayer pump engineered for highly demanding fluid displacement tasks. Powered by an integrated 4-inch drive pulley, this high-efficiency pump operates exceptionally within a 600 to 800 RPM range, making it a reliable workhorse for uniform liquid delivery. Inside its compact 45 x 34 x 42.5 cm form factor lies a robust 3-piston system featuring a precision-engineered 34mm piston diameter and 26mm stroke length. This advanced engineering allows the pump to comfortably deliver an outstanding suction capacity of 60 to 80 Liters Per Minute (LPM) while sustaining an adjustable working pressure range of 15 to 35 kgf/cm². Designed to minimize power loss while maximizing output, the Veto CV-S100GF is the ultimate asset for large-scale agricultural operations, pest control, public sanitation, and commercial vehicle cleaning setups.

Features

Triplex Plunger Mechanism: Built with three heavy-duty 34mm pistons that reduce internal vibration and ensure a seamless, non-pulsating high-pressure fluid stream.
Balanced 4-Inch Drive Pulley: Features a rugged iron pulley designed for easy and efficient belt-driven coupling to standard electric motors or diesel engines.
High-Discharge Suction Valve: Achieves up to 80 LPM suction capacity, effortlessly feeding multiple commercial long-range spray guns at once.
Adaptive Pressure Regulator: Equipped with an adjustable bypass valve to safely manage and lock operational pressure anywhere between 15 and 35 kgf/cm².
Anti-Corrosive Compact Body: Housed in a durable cast-alloy frame occupying just 45 x 34 x 42.5 cm, perfectly optimized to withstand harsh agricultural and outdoor elements.
