Jindal Gold 1 HP 10 Stage V4 Single Phase Water Cooled Submersible Pump, 220ft Head, 3900 LPH

Brand: Generic ( Made in India )

Jindal Gold 1 HP 10 Stage V4 Single Phase Water Cooled Submersible Pump, 220ft Head, 3900 LPH

Name: Jindal Gold 1 HP 10 Stage V4 Single Phase Water Cooled Submersible Pump, 220ft Head, 3900 LPH
Brand: Generic ( Made in India )
SKU: TI-JG-79452
Price: 7149 INR
Availability: InStock
Rating: 5.00 (1 reviews)

SKU: TI-JG-79452

MRP : ₹11800 ₹7149

39% OFF!

Get Extra ₹107 OFF on Prepaid Orders

Estimated Delivery By: Aug 5 - Aug 7

Easy Return
& Refund

Quality
Assurance

Trusted
Delivery

After Sales
Assistance

Buyer
Protection

₹7149 (Including GST)

MRP : ₹11800

39% OFF!

Get Extra ₹107 OFF on Prepaid Orders

QTY :

Add to Cart

Buy Now

1 HP 10 stage submersible pump.

220ft maximum head delivery.

65 LPM max water discharge.

Designed for 4 inch borewells.

Country of origin: India

Brand: Generic ( Made in India )
Power : 1 hp
Weight (Approx.) : 13 kg
Flow Rate : 65 lpm
Head : 67 meter

Product Name: Borewell Submersible Pump
Wattage: 0.75 kW
Supply Voltage: 150-220 Volt, 50 Hz, AC Power Supply
Electricity Connection: Single Phase
No Of Stages: 10 Stage
Pump Type: V4
Suitable Bore Size: 4 inch
Max. Head Range: 220 Feet (67 Meter)
Max. Flow/Discharge Rate: 65 LPM (3900 LPH)
Pipe Size (Suction x Delivery): 25 x 25 mm (1 x 1 inch)
Cooling Type: Water Cooled

Material Of Construction:

Motor Body: Stainless Steel
Motor Rotor: Copper
Impeller: Noryl (Ivory)
Pump Shaft: SS-410
Winding Material: Copper

A water-cooled submersible pump is designed to operate fully submerged in water, with its motor's heat dissipated directly into the surrounding pumped liquid to ensure continuous and efficient operation. This borewell submersible pump is extensively used for domestic, agricultural, and industrial water supply, dewatering, and wastewater management, especially where reliable and continuous pumping from submerged underground sources is required.

Features

Corrosion resistant stainless steel body
Specially designed for low voltage working
High electrical and mechanical efficiency
Higher heat dissipation
Dynamically balanced rotor and rotating parts for uniform clearance
Specially designed bearing to withstand axial thrust loads
Designed for high voltage fluctuation
Low power consumption with high performance output

Accessories

Control Panel
30 Meter Submersible Cable
Safety Wire

Applications

Drinking water supply and domestic & community water supply.
Drip irrigation, sprinkler irrigation, and gardening applications.
Housing complexes, hospitals, and high-rise buildings.
Fire fighting systems, landscaping, fountains, and service stations.
De-watering of mines, cooling water circulation, and booster applications.

Warranty

1 Year WARRANTY on manufacturing defects only.

Warranty Terms

Dry Run Accidental Damages Are not covered in the warranty.
For claiming the warranty please drop a mail at [email protected] with proper bill or Order ID.
You have to send the product to the sellers warehouse.
Buyer has to bear the courier charges of both side for sending the product.

Usage

Lower the unit fully submerged into a 4-inch or larger borewell casing.
Connect the pump to a 150–220V AC single-phase power supply via the included control panel.
Ensure proper pipe fittings and electrical connections before turning on the power supply.
Never operate the pump without water in the borewell to prevent dry run damage.

Maintenance

Regularly check electrical connections and control panel terminals for loose wiring or corrosion.
Ensure the borewell has sufficient water levels to prevent dry running.
Inspect delivery pipes for clogging or sediment buildup to maintain optimal flow rates.
Store in a dry place if uninstalled or unused for long periods.
