• Engine Type : Air Cooled
• Suction Port Diameter : 110 mm ( 4 inch)
• Discharge Port Diameter : 110 mm ( 4 inch)
• Maximum Head : 30 m 98 Ft
• Maximum Suction : 8 m 26 ft
• Maximum Flow : 700 L/ min

Features

• Potable Design : It is designed to handle the most toughest jobs like irrigating a field, draining a pool in no time, pump out a flooded trench, fill or empty a water storage tank.
• Extra Lifting Capacity:  It has higher suction power and give high discharge in its operating range.

Accessories

• Foot Valve
• Washers
• Clamps
• Coupling
• Toolkit
•  Manual
•  Rubber Feet

Applications

• Used in agriculture fields, irrigation, farming land, gardening, farm-houses, fountains, drain water from a basement or shallow flooded areas, drain and fill a swimming pool or dam.

Usage

• Fill the tank with unleaded petrol
• Attach the suction hose to the pump & intake and the delivery hose to the outlet.
• Ensure all connections are secure and leak-free.
• You prime the pump by filling it with water through the priming plug. This removes air and prepares it to draw water effectively

• Ensure the fuel valve is open, allowing petrol to flow to the engine .If the engine is cold, engage the choke.
• Pull the recoil starter cord gently until you feel resistance, then give it a sharp tug.
• Repeat until the engine starts.
• Once the engine starts, gradually disengage the choke as it warms up.
• Adjust the throttle to control the water flow rate

• Turn off the engine and allow it to cool before refueling.
