HPM 150 Amp Recoil and Self Start Portable Diesel Run DC Welder cum Generator with Battery

Easy Returns

Quality Assurance

Trusted Delivery

After Sales Assistance

Short Description

150 Amp Diesel DC Welder & Generator with Battery

Max. AC Output 2 kVA

Welds Upto 3.17 mm Electrode

Description

HPM 150 Amp Recoil and Self Start Portable Diesel Run DC Welder cum Generator with Battery

Features:

• Most Portable & Low Cost Arc Welding Machine Suitable for General Purpose Structural Welding, Light and medium Welding Jobs.

Specification:

• Model No. : GE-W5500D
• Product Type : Welder Generator
• Brand : HPM
• Fuel Used : Diesel
• Starting Type : Recoil & Self Starter
• Dimensions : 630x500x600  mm
• Weight : 55Kg (Approx)

DC Welding :

• Maximum Output (Duty Cycle 60%) : 150 Amps, 4 kW

• Working Voltage : 20 -30 V
• Open Circuit Voltage : 60 Volt (Maximum)
• Current Regulation : 40-150 Amps
• Rectifying Mode : SCR, Phase Controlled 3-phase, Rectifying Bridge
• Maximum Electrode Diameter : 2.6 - 3.17 mm


AC Generator :

• Max. AC Output : 2000 VA
• Type : Brush less with Rear Earth Magnet Rotor
• AC. Voltage On Power Mode (No Load) : 250 Volts (No Load) ± 10 Volts, Single Phase
• Rated Current : 7.5 Amps.
• NFB : 7.5 Amps.
• Rated Power : 1800 VA
• Frequency : 58 to 60 Hz.

• Class of Insulation : F

Engine :

• Model : TP170FA
• Type : 4-Stroke, OHV, Single Cylinder, Direct Injection, Swirl Chamber, Inclined type
• Bore x Stroke : 70x60 mm
• Displacement : 231 cc
• Starting System : Recoil / Self Start
• Fuel : Standard Diesel
• Fuel Tank Capacity : 3.5 Liters
• Fuel Consumption Ltr/Hr : 0.65 Ltr/hr
• Continuous Operating Hour : 5.5 hr
• Lube. Oil Capacity : 800 ml
• Lubricating Oil Consumption : 3.2 gm /hr

Accessories :

• AC Plug
• Tool Kit 1 Set
• Welder Holder with Cable 1 Set
• Earthling Clamp with Cable 1 Set
• Oil Funnel
• Owner’s Manual
• Battery Terminal 1 Set
• Battery Tray & Holding Set

Note :

• Do not use the welder for work other than welding.
• Do not touch the live part.
• Do not solder in places where skimming, cleaning and spraying are required.
• When using, please wear a protective cover or protective clothing.
