Single & Double Phase Welding Machine ARC 400, Welds 5mm Continuously

Easy Returns

Quality Assurance

Trusted Delivery

After Sales Assistance

Short Description

3 Board

Generator Friendly

120-560 Universal Voltage

Best welding performance

Suitable Welding Rod : 2.5 to 5 mm continuously(No. 12, 10, 8 & 6 )

Description

Single & Double Phase Welding Machine ARC 400, Welds 5mm Continuously

Features:

• 3 Board
• 120-560 Universal Voltage
• Generator Friendly
• Best welding performance

Application:

• For welding upto 5mm SS & MS rods for Grill Gate Welding.
• Suitable Welding Rod : 2.5 to 5 mm continuously(No. 12, 10, 8 & 6 )

Specification:

• Model No. : Schwer ARC D
• Product Type : Welding machine
• Brand : Schwer
• Phase : Single & Double Phase
• Efficiency : 80%
• Duty Cycle : 60%
• Power Factor : 0.73
• Protection Class : IP21
• Insulation Class : F
• Rated Input Power(KVA) : 14
• Rated Input Current(A) : 35
• Rated Output Voltage(V) : 65
• Output Current Range(A) : 20-400
• Electrode Diameter : 2.5mm To 5mm (No. 12, 10, 8 & 6 )
• Rated Input Voltage(V) : AC 220V±10% Single Phase, AC 380V±10% Double Phase
• Weight : 15 Kg

Accessories:

• 1 x Welding Machine
• 1 x Operator's Manual
• 1 x Working Clamp
• 1 x Earthing Clamp

Note :

• Do not use the welder for work other than welding.
• Do not touch the live part.
• Do not solder in places where skimming, cleaning and spraying are required.
• When using, please wear a protective cover or protective clothing.
