Brand: Generic (Imported)
ARC 300 Single Phase IGBT Welding Machine, Suitable for 2.5mm, 3.15mm, 4mm Rod
SKU: BP-ARC-250-ss
60 people have bought this recently
Delivery By: Jun 21 - Jun 23
MRP : ₹7420 ₹4990
33% OFF!
60 people have bought this recently Delivery By: Jun 21 - Jun 23 Easy Return
& Refund
& Refund
Quality
Assurance
Assurance
Trusted
Delivery
Delivery
After Sales
Assistance
Assistance
Buyer
Protection
Protection
₹4990 (Including GST)
MRP : ₹7420
33% OFF!
Get Extra ₹75 OFF on Prepaid Orders
QTY :
-
1
+
Short Description
ARC 300 Single Phase Welding Machine
IGBT Welding Machine
300 Amp Current
The suitable electrodes are 2.5 mm, 3.2 mm, 4mm
Country of origin: China
Specifications
- Brand: Generic (Imported)
- Weight (Approx.) : 8 kg
- Output Current Range : 300 amp
- Technology : IGBT
- Model No. : ARC 300
- Rated Input Voltage : AC 220V+10%
- Electricity Connection : Single Phase
- Frequency (Hz) : 50/60Hz
- Rated Input Capacity (KVA) : 12
- Rated Input Current : 22V
- Output Voltage : 80 V
- Duty Cycle (%) : 60%
- Rated Output Current range : 20-300A
- Rated Output Voltage range : 20.8 - 27.5 V
- Efficiency % : 85%
- Insulation Class : F
- Case Protection class : Ip23
- Suitable electrode (MM) : 2.5 mm,3.15mm, 4mm
- Cable Length: 1-1.5m (Approx.)
Suitable For :
- 2.5 mm x 3.15 mm x 4 mm (MS Rod)
- 2.5 mm x 3.15 mm (SS Rod)
Description
A strong instrument made for demanding welding jobs is a 300 amp welding machine. Because of its high output current capability, it may be used to weld thicker materials and complete tough tasks in a variety of industrial and construction environments. A 300 amp welding machine is a strong and adaptable instrument that can be used by serious enthusiasts as well as professional welders to efficiently complete large tasks.
Features
:- Has the auto-compensation function to mains voltage fluctuation, powerful ability in anti-fluctuation of mains, welding current stable and reliable.
- Automatic over-voltage and over-current protection function
- Good Arc Force Compensation
- Reliable performance, small dimension, low weight, high efficiency, and energy saving
- Acidic and alkaline welding rods of various brands can be used for welding
- All black metals such as low carbon steel, mild carbon steel, and alloy steel structure.
Accessories
:- 1 x Operator's Manual
- 1 x Working Clamp
- 1 x Earthing Clamp
Applications
:- Repair and maintenance: Welding machines are also used for repair and maintenance purposes, such as fixing broken metal parts, reinforcing structures, and restoring equipment.
- Construction: Welding machines are commonly used in construction projects for joining steel beams, girders, and other structural components.
- Automotive industry: Welding machines are used to join different parts of a vehicle such as chassis, engine, and body.
- Manufacturing: Welding machines are used to join metal components in the manufacturing industry, including machinery and electronics.
Note :
- Do not use the welder for work other than welding.
- Do not touch the live part.
- Do not solder in places where skimming, cleaning and spraying are required.
- When using, please wear a protective cover or protective clothing.
