Brand: Made in India
1 HP 3" inch V3 SS Borewell Submersible Pump Set-20 Stage, 300 feet Max. Head & 45 LPM
SKU: PH-SK-20220619
Regular Price : ₹9000
Offer Price : ₹7590 (Including GST)
Get extra ₹228 Discount (On Checkout)
Out of Stock
Out of Stock
Easy
Returns
Quality
Assurance
Trusted
Delivery
After Sales
Assistance
Short Description
1 HP V3 SS Borewell Submersible Pump Set
Single phase motor with 2880 RPM
Discharge rate 45 LPM & Head Range 300 feet (max)
Description
1 HP 3" inch V3 SS Borewell Submersible Pump Set-20 Stage, 300 feet Max. Head & 45 LPM
Features :
- Better design equates to higher efficiency and lower energy use.
- Lightweight - Installation is simple.
- Running in silence
Specifications :
- Model No. : SKS-2
- Product Type : Borewell Submersible Pump Set
- Brand : Made in India
- Power Source : Electric
- Power Supply : 240 V AC Supply
- Electricity connection : Single Phase
- Motor Power : 1 HP (0.75 kW)
- No Load Speed : 2880 RPM
- No of Stages : 20
- Motor OD : 73 mm
- Outlet Size : 25.4 mm
- Max Head Range : 300 feet
- Max. Flow Rate : 45 LPM
Material details :
- Motor body & Pump body : Stainless Steel 304 Grade
- Rotor : EC Grade Copper & Silicon Stamping
- Casting : Graded Cast Iron
- Winding : Copper winding & High Insulation Capacity
- Stamping : M-45 Grade Silicon
- Bushing : Gunmetal LT-B4
- Shaft Material : SS 410 &431 Grade
- Bowl Set : Norly with SS Ring
- Thrust Bearing : SS Segment Teflon Plate & Carbon
- Oil Seal Material : Nitrite Rubber
- Sand Guard Material : Stainless Steel 304 Grade
- Hardware : Stainless steel
Suitable For :
- 3 inch (80 mm) Boring
Applications :
- Irrigation and Drip irrigation.
- Sprinkler, Gardening, Nursery and Bungalows.
- High Story Building & complexes.
- Fountains.
- Small Farms.
- Industrial water supply schemes
Note :
- 15 feet per stage
